Mitsubishi Outlander I (2002-2009) heated seat switch Wiring diagrams
This page contains all the electrical diagrams for the component. heated seat switch, in which he is found in the car Mitsubishi Outlander I (2002-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram heated seat switch (1 of 2)
BLK WIRE
ETACS-ECU (BEHIND LEFT SIDE OF DASH)
FUSE 12
FUSE 25
GRN WIRE
HEATED SEAT RELAY (ON ETACS-ECU)
HEATED SEAT SWITCH
HI LO LO HI OFF OFF OFF ILL
HI LO OFF
HI OFF ILL
HOT AT ALL TIMES
LEFT HEATED SEAT
LO HI OFF
ON OFF
ON OFF THERMOSTAT
PASSENGER COMPARTMENT RELAY BOX
RED WIRE
RELAY ENERGIZED
RIGHT HEATED SEAT
SEAT BACK HEATER
SEAT CUSHION HEATER
THERMOSTAT
THERMOSTAT SEAT CUSHION HEATER ON OFF
WHT WIRE
Go to component -> Heated seats circuit -> HEATED SEAT SWITCH
Wiring diagram heated seat switch (2 of 2)
1 5 D-06
10 C-10 25 C-09
5 10 PNK WIRE
A/C CONTROL PANEL
ASC OFF SWITCH
AUDIO VISUAL NAVIGATION UNIT
AUTO-CRUISE CONTROL SWITCH
BLK WIRE
BLK/WHT WIRE
BRN WIRE
C-202 CLOCK SPRING (UNDER STEERING WHEEL)
C-204
C-311
C-315
C-317
CENTER PANEL UNIT
COLUMN ECU
COLUMN SWITCH
COMBINATION METER
COURTESY LAMPS CIRCUIT
DRIVE MODE SELECTOR
ETACS-ECU (BEHIND LEFT SIDE OF DASH)
FUSE 12
FUSE 20 FUSE 8
FUSE 9
GRN/WHT WIRE
GRY WIRE
HEAD
HEATED SEAT SWITCH
HOT AT ALL TIMES
INTERFACE CIRCUIT
KEY REMINDER SWITCH IGNITION KEY HOLE ILLUMINATION LIGHT
LED DRIVE CIRCUIT
LIGHTING SWITCH
NCA WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH
RADIO, CD PLAYER OR CD CHANGER
REAR DISPLAY SPARE CONNECTOR (IN LEFT "C" PILLAR)
REAR DISPLAY UNIT
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
RHEOSTAT
RIGHT HEATED SEAT
SHIFT SWITCH ASSEMBLY
STEERING AUDIO SWITCH
STEERING VOICE CONTROL SWITCH
TAIL
TAILLIGHT CONTROL CIRCUIT
VIO WIRE
WHT WIRE
YEL/VIO WIRE
Go to component -> Instrument illumination circuit -> HEATED SEAT SWITCH
