Mitsubishi Outlander I (2002-2009) 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 c-14 pnk Wiring diagram
This page shows the only wiring diagram for the component.18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 c-14 pnk, which is found in the car Mitsubishi Outlander I (2002-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 c-14 pnk (1 of 1)
18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 C-14 PNK WIRE
40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 C-16
64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 C-18
ANTENNA AMPLIFIER
AUDIO SWITCH PANEL
BLK WIRE
BLU WIRE
BRN WIRE
C-315
C-317
CENTER PANEL UNIT
COMPUTER DATA LINES SYSTEM
DIN CABLE
ETACS-ECU (BEHIND LEFT SIDE OF DASH)
FUSE 16
FUSE 7
GRN WIRE
GRN/WHT WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY 2 ENERGIZED
LCD PANEL (AUDIO)
NCA WIRE
ORG/ WIRE
PNK WIRE
RADIO, CD CHANGER
RED WIRE
RED/WHT WIRE
ROOF ANTENNA
SATELLITE RADIO TUNER (IF EQUIPPED)
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, without rear entertainment, with amplifier (1 of 2) -> 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 C-14 PNK WIRE
