Mitsubishi Outlander Sport I facelift 2 (2015-2019) gnd vcc lf sens sens sens lr sens Wiring diagram
This page shows the only wiring diagram for the component.gnd vcc lf sens sens sens lr sens, which is found in the car Mitsubishi Outlander Sport I facelift 2 (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd vcc lf sens sens sens lr sens (1 of 1)
BLK WIRE
BLU WIRE
C-17
C-26
C-411
C-415
CAN DRIVE CIRCUIT
CAN TRANSCEIVER CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
D-48-1
D-48-2
DR STPS GND
DR STPS PWR
DRIVER SEAT BELT IND
ETACS-ECU
FUSE 17
GND VCC LF SENS SENS SENS LR SENS
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTERFACE CIRCUIT
LCD (SRS)
LED DRIVE CIRCUIT
LEFT FRONT WEIGHT SENSOR
LEFT REAR WEIGHT SENSOR
NCA WIRE
OCCUPANT CLASSIFICATION ECU
PNK WIRE
RE SENS RR SENS
RED WIRE
RIGHT FRONT WEIGHT SENSOR
RIGHT REAR WEIGHT SENSOR
SEAT SLIDE SENSOR
SRS IND
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 4) -> GND VCC LF SENS SENS SENS LR SENS
