Mitsubishi Montero III (1999-2006) yel/org Wiring diagrams
This page contains all the electrical diagrams for the component. yel/org, in which he is found in the car Mitsubishi Montero III (1999-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram yel/org (1 of 5)
"G" SENSOR (BEHIND CENTER CONSOLE)
ABS ECU (IN RIGHT REAR CORNER OF ENGINE COMPARTMENT)
ABS INDICATOR
ABS RELAY (ON RIGHT REAR SIDE OF ENGINE COMPARTMENT)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
COMBINATION METER
DATA LINK CONNECTOR 1 (UNDER LEFT SIDE OF DASH, NEAR RELAY BOX)
DEDICATED FUSE 9
ECU (BEHIND RIGHT KICK PANEL)
FUSIBLE LINK 14 (ON POSITIVE BATTERY TERMINAL)
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN
HOT IN RUN OR START
JOINT CONNECTOR 1
JOINT CONNECTOR 2
JOINT CONNECTOR 5
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT FRONT WHEEL SPEED SENSOR (ON LEFT FRONT WHEEL HUB)
LEFT REAR WHEEL SPEED SENSOR (ON LEFT REAR WHEEL HUB)
MULTI- PURPOSE FUSE 4
MULTI- PURPOSE FUSE 8
NCA WIRE
RIGHT FRONT WHEEL SPEED SENSOR (ON RIGHT FRONT WHEEL HUB)
RIGHT REAR WHEEL SPEED SENSOR (ON RIGHT REAR WHEEL HUB)
RUN WIRE
STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
TRANSMISSIONS SYSTEM
WHT/BLU WIRE
WHT/RED WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Anti-lock brakes circuit, 4-wheel drive -> YEL/ORG WIRE
Wiring diagram yel/org (2 of 5)
1 7 DATA LINK CONNECTOR 1 (UNDER LEFT SIDE OF DASH, NEAR RELAY BOX)
ABS ECU (IN RIGHT REAR CORNER OF ENGINE COMPARTMENT)
ABS INDICATOR
ABS RELAY (ON RIGHT REAR SIDE OF ENGINE COMPARTMENT)
BLK WIRE
BLK/ WHT WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
COMBINATION METER
DEDICATED FUSE 9
FUSIBLE LINK 14 (ON POSITIVE BATTERY TERMINAL)
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN
HOT IN RUN OR START
JOINT CONNECTOR 1
JOINT CONNECTOR 2
JOINT CONNECTOR 5
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT FRONT WHEEL SPEED SENSOR (ON LEFT FRONT WHEEL HUB)
LEFT REAR WHEEL SPEED SENSOR (ON LEFT REAR WHEEL HUB)
MULTI- PURPOSE FUSE 4
MULTI- PURPOSE FUSE 8
NCA WIRE
RIGHT FRONT WHEEL SPEED SENSOR (ON RIGHT FRONT WHEEL HUB)
RIGHT REAR WHEEL SPEED SENSOR (ON RIGHT REAR WHEEL HUB)
RUN WIRE
STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
WHT/ BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Anti-lock brakes circuit, rwd -> YEL/ORG WIRE
Wiring diagram yel/org (3 of 5)
ABS ECU (IN RIGHT REAR CORNER OF ENGINE COMPT)
AUTO-CRUISE CONTROL ECU (BEHIND LEFT KICK PANEL)
BLK WIRE
BLU WIRE
BLU/ WHT WIRE
BLU/WHT WIRE
COMBINATION METER
DATA LINK CONNECTOR 1
DATA LINK CONNECTOR 2 (UNDER LEFT SIDE OF DASH, NEAR RELAY BOX)
DEDICATED FUSE 1
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
ENTRY
ETACS-ECU
GRN WIRE
GRN/RED WIRE
GRY/RED WIRE
HOT AT ALL TIMES
IOD OR STORAGE CONNECTOR (IN ENGINE COMPARTMENT RELAY BOX)
JOINT CONNECTOR 2
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEYLESS ENTRY RECEIVER ECU (IN LEFT SIDE OF LUGGAGE COMPT)
LT GRN/YEL WIRE
ORG/ WIRE
POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
RED WIRE
RED/BLK WIRE
SRS-ECU (BEHIND CENTER CONSOLE)
VEHICLE SPEED SENSOR
W/ KEYLESS
W/O KEYLESS ENTRY
WHT/ BLU WIRE
YEL WIRE
YEL/ORG WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Computer data lines circuit -> YEL/ORG WIRE
Wiring diagram yel/org (4 of 5)
1 2 3 4 5 6 C-24
11 12 AIR BAG DRIVE CIRCUIT
13 14 15 16 17 18 19 20 IGNITION
7 8 GROUND WARNING LIGHT
9 10 AIR BAG DRIVE CIRCUIT
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
C-02
C-04
C-24
CLOCK- SPRING
COMBINATION METER
CONNECTOR LOCK SWITCH (CONNECTOR COUPLED: ON) (CONNECTOR UNCOUPLED: OFF)
D-06
D-13
D-14
DATA C-24
DATA LINK CONNECTOR (PARTIAL) (UNDER LEFT SIDE OF DASH, NEAR RELAY BOX)
DETECTION CIRCUIT
DRIVER'S SIDE AIR BAG MODULE SQUIB
FUSE 7
FUSE 8
GRN WIRE
GRN/YEL WIRE
HOT IN ON OR START
IGNITION
J/C 2 (BEHIND RIGHT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
OFF
OFF ON
ON OFF
RED WIRE
SRS INDICATOR
SRS-ECU (BEHIND CENTER CONSOLE)
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> YEL/ORG WIRE
Wiring diagram yel/org (5 of 5)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CRUISE CONTROL SYSTEM
DATA LINK CONNECTOR (PARTIAL)
DEDICATED FUSE 1
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
ENGINE COOLANT TEMPERATURE SENSOR (FRONT CENTER OF ENGINE)
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/RED WIRE
HOT AT ALL TIMES
IOD OR STORAGE CONNECTOR
J/C 2 (BEHIND RIGHT SIDE OF DASH)
J/C 4 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LT GRN/RED WIRE
MANIFOLD DIFFERENTIAL PRESSURE SENSOR (LEFT REAR OF ENGINE COMPT)
NCA WIRE
PNK 13 14 15 16 17 18 19 WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
THROTTLE POSITION SENSOR (ON THROTTLE BODY)
VOLUME AIR- FLOW SENSOR (IN AIR CLEANER DUCT)
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 3.5l (3 of 4) -> YEL/ORG WIRE
