Mitsubishi Montero III (1999-2006) up right front power window switch on off Wiring diagram
This page shows the only wiring diagram for the component.up right front power window switch on off, which is found in the car Mitsubishi Montero III (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram up right front power window switch on off (1 of 1)
BLK WIRE
BLU WIRE
DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN)
DOWN
DOWN UP
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ETACS-ECU
FUSIBLE LINK 4 FUSE 18
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ILLUM
JOINT CONNECTOR 6 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
LEFT FRONT DOOR SWITCH
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SUB SWITCH
LOCK
LOCK SWITCH
MULTI-PURPOSE FUSE 6
NCA WIRE
OFF
OFF OFF ON ON
OFF ON
ON OFF DOWN
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR SWITCH
RIGHT FRONT POWER WINDOW MOTOR
RIGHT FRONT POWER WINDOW SUB SWITCH
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SUB SWITCH
UNLOCK
UP LEFT FRONT POWER WINDOW SWITCH ON
UP LEFT REAR POWER WINDOW SWITCH ON OFF
UP RIGHT FRONT POWER WINDOW SWITCH ON OFF
UP RIGHT REAR POWER WINDOW SWITCH ON OFF
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Power windows circuit -> UP RIGHT FRONT POWER WINDOW SWITCH ON OFF
