Mitsubishi Montero III (1999-2006) starting/charging system engine controls system Wiring diagram
This page shows the only wiring diagram for the component.starting/charging system engine controls system, which is found in the car Mitsubishi Montero III (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram starting/charging system engine controls system (1 of 1)
A/T TEMP IND
ABS IND.
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLK/WHT WIRE
BRAKE FLUID LEVEL SWITCH (IN LEFT REAR CORNER OF ENGINE COMPT)
BRAKE IND
CHARGE IND
CHK ENG IND
COMBINATION METER
CRUISE CONTROL AND SOUND SYSTEMS
CRUISE CONTROL SYSTEM
CRUISE IND
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE GAUGE UNIT (ON RIGHT SIDE OF ENGINE)
ETACS-ECU
FUEL GAUGE
FUEL IND
FUSE 1
FUSE 8 FUSE 7
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HI-BEAM IND
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUM
IMMOBILIZER IND
JOINT CONNECTOR 1
JOINT CONNECTOR 5
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LT GRN/RED WIRE
NCA WIRE
OIL IND
OIL PRESSURE SWITCH (ON LOWER LEFT FRONT OF ENGINE)
PARKING BRAKE SWITCH
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
SEAT BELT IND
SPEEDOMETER
SRS IND
STARTING/CHARGING SYSTEM ENGINE CONTROLS SYSTEM
TACHOMETER
TEMPERATURE GAUGE
TO COMBINATION METER (D INDICATOR) (DIAGRAM 2 OF 2)
VEHICLE SPEED SENSOR (ON TRANSMISSION TAILSHAFT)
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> STARTING/CHARGING SYSTEM ENGINE CONTROLS SYSTEM
