Mitsubishi Montero III (1999-2006) right door lock key cylinder switch Wiring diagrams

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE DATA LINK CONNECTOR 1 (UNDER LEFT SIDE OF DASH, NEAR RELAY BOX) DIODE (THEFT ALARM HORN CIRCUIT) (LEFT END OF DASH) DOOR LOCKS SYSTEM DOOR LOCKS, INTERIOR LIGHTS SYSTEM ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL) ETACS-ECU FUSE 1 FUSE 3 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE HEADLIGHTS SYSTEM HOOD SWITCH JOINT CONNECTOR 5 (BEHIND UPPER RIGHT SIDE OF DASH) HORNS SYSTEM HOT AT ALL TIMES HOT IN RUN OR START IND SECURITY INDICATOR IOD OR STORAGE CONNECTOR JOINT CONNECTOR 1 (BEHIND UPPER RIGHT SIDE OF DASH) JOINT CONNECTOR 2 (BEHIND UPPER RIGHT SIDE OF DASH) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) KEY REMINDER SWITCH (CLOSED WHEN KEY IS REMOVED) LEFT DOOR LOCK KEY CYLINDER SWITCH LEFT FRONT DOOR LOCK ACTUATOR (REAR OF LEFT FRONT DOOR) LEFT FRONT DOOR SWITCH LEFT REAR DOOR LOCK ACTUATOR (REAR OF LEFT REAR DOOR) LOCK LIFTGATE LOCK KEY CYLINDER SWITCH LIFTGATE SWITCH LOCK LOCK OFF UNLOCK MULTI- PURPOSE FUSE 8 NCA WIRE OFF RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT DOOR LOCK KEY CYLINDER SWITCH RIGHT FRONT DOOR LOCK ACTUATOR (REAR OF RIGHT FRONT DOOR) LOCK RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR LOCK ACTUATOR (REAR OF RIGHT REAR DOOR) LOCK RIGHT REAR DOOR SWITCH LEFT REAR DOOR SWITCH THEFT ALARM HORN RELAY (BEHIND RIGHT SIDE OF GLOVE BOX) THEFT- ALARM HORN UNLOCK W/ KEYLESS ENTRY WHT WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE DATA LINK CONNECTOR 1 (UNDER LEFT SIDE OF DASH, NEAR RELAY BOX) ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL) ETACS-ECU FROM ETACS ECU (JUNCTION BLOCK) (DIAGRAM 1 OF 2) FUSE 5 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/YEL WIRE HAZARD WARNING RELAY (BEHIND RIGHT SIDE OF GLOVE BOX) HOT AT ALL TIMES HOT IN ACC JOINT CONNECTOR 1 (BEHIND UPPER RIGHT SIDE OF DASH) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) JUNCTION CONNECTOR 2 KEYLESS ENTRY RECEIVER ECU (IN LEFT SIDE OF LUGGAGE COMPT) LEFT DOOR LOCK KEY CYLINDER SWITCH LIFTGATE LOCK KEY CYLINDER SWITCH LOCK LOCK UNLOCK MULTI- PURPOSE FUSE 2 NCA WIRE POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH) POWER WINDOW SUB SWITCH DOOR LOCK SWITCH RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RIGHT DOOR LOCK KEY CYLINDER SWITCH UNLOCK

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL) ETACS-ECU FUSE 1 FUSE 3 FUSE 8 GRN/BLK WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR START IOD OR STORAGE CONNECTOR JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) KEY REMINDER SWITCH LEFT DOOR LOCK KEY CYLINDER SWITCH LEFT FRONT DOOR LOCK ACTUATOR (REAR OF LEFT FRONT DOOR) LEFT FRONT DOOR SWITCH LEFT REAR DOOR LOCK ACTUATOR (REAR OF LEFT REAR DOOR) LIFTGATE DOOR LOCK ACTUATOR (IN LOWER RIGHT SIDE OF LIFTGATE) LOCK LOCK UNLOCK NCA WIRE POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH) POWER WINDOW SUB SWITCH (DOOR LOCK UNLOCK LOCK SWITCH) RED WIRE RED/ BLU WIRE RED/BLK WIRE RIGHT DOOR LOCK KEY CYLINDER SWITCH RIGHT FRONT DOOR LOCK ACTUATOR (REAR OF RIGHT FRONT DOOR) RIGHT REAR DOOR LOCK ACTUATOR (REAR OF RIGHT REAR DOOR) SOLID STATE UNLOCK UNLOCK LOCK
