Mitsubishi Montero III (1999-2006) rear height motor Wiring diagrams
This page contains all the electrical diagrams for the component. rear height motor, in which he is found in the car Mitsubishi Montero III (1999-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear height motor (1 of 2)
BLK WIRE
BLU WIRE
DRIVER'S SIDE POWER SEAT ASSEMBLY
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FR RR
FRONT HEIGHT
FRONT HEIGHT MOTOR
FUSIBLE LINK 4
HOT AT ALL TIMES
LUMBAR SUPPORT MOTOR
LUMBAR SUPPORT SWITCH
NCA WIRE
POWER SEAT SWITCH
REAR HEIGHT
REAR HEIGHT MOTOR
RECLINING
RECLINING MOTOR
SLIDE
SLIDE MOTOR
UP DN
UP RR
Go to component -> Driver seat circuit -> REAR HEIGHT MOTOR
Wiring diagram rear height motor (2 of 2)
Go to component -> Passenger"s power seat circuit -> REAR HEIGHT MOTOR
