Mitsubishi Montero III (1999-2006) rear blower unit Wiring diagrams
This page contains all the electrical diagrams for the component. rear blower unit, in which he is found in the car Mitsubishi Montero III (1999-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear blower unit (1 of 3)
12 13 PNK WIRE
2 3 4 5 6 7 8 9 10 11 12 13 14 GND
A/C COMPRESSOR CLUTCH RELAY
AIR CONDITIONING SENSOR
BLK WIRE
BLK/YEL WIRE
BLOWER MOTOR
BLOWER RESISTOR
BLOWER SWITCH
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
CONDENSER FAN CONTROL RELAY
CONDENSER FAN MOTOR
DUAL PRESSURE SWITCH (AT LOWER LEFT SIDE OF A/C CONDENSER, ON LIQUID LINE)
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSE 10
FUSE 11
FUSE 18
FUSE 19
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/BLU WIRE
HI LO
HIGH- PRESSURE SIDE
HOT AT ALL TIMES
ILLUM
JOINT CONNECTOR 1 (LEFT SIDE OF ENGINE COMPT)
JOINT CONNECTOR 2
JOINT CONNECTOR 3 (LEFT SIDE OF ENGINE COMPT)
JOINT CONNECTOR 7 (BEHIND LEFT SIDE OF DASH)
JOINT CONNECTOR 8 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
LOW- PRESSURE SIDE
LT GRN WIRE
LT GRN/RED WIRE
MAGNETIC VALVE
OFF
OFF ON
ON OFF
ORG/ WIRE
PNK WIRE
POWER
REAR BLOWER RELAY
REAR BLOWER UNIT
REAR COOLER CONTROL UNIT (ON BOTTOM OF HVAC ASSEMBLY)
REAR COOLER SWITCH
REAR COOLER UNIT
REAR FAN CONTROL SWITCH (FRONT)
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
SOLID STATE
TEMPERATURE SWITCH
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, with rear cooler (2 of 2) -> REAR BLOWER UNIT
Wiring diagram rear blower unit (2 of 3)
2 3 4 5 6 7 8 9 GND
A/C COMPRESSOR CLUTCH RELAY
AIR CONDITIONING SENSOR
BLK WIRE
BLK/YEL WIRE
BLOWER MOTOR
BLOWER RESISTOR
BLOWER SWITCH
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
CONDENSER FAN CONTROL RELAY
CONDENSER FAN MOTOR
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
FENDER PANEL)
FUSE 10
FUSE 11
FUSE 19
GRN/WHT WIRE
GRN/YEL WIRE
GRY/BLU WIRE
HI LO
HOT AT ALL TIMES
ILLUM
JOINT CONNECTOR 1 (LEFT SIDE OF ENGINE COMPT)
JOINT CONNECTOR 2
JOINT CONNECTOR 3 (LEFT SIDE OF ENGINE COMPT)
JUNCTION BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
LT GRN WIRE
LT GRN/RED WIRE
MAGNETIC VALVE
ON OFF
ORG/ WIRE
PNK GND WIRE
PNK WIRE
PWR SOURCE
REAR BLOWER RELAY
REAR BLOWER UNIT
REAR COOLER CONTROL UNIT (ON BOTTOM OF HVAC ASSEMBLY)
REAR COOLER SWITCH
REAR COOLER UNIT
REAR FAN CONTROL SWITCH (FRONT)
REAR FAN SWITCH
RED WIRE
RED/YEL WIRE
TEMPERATURE SWITCH
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/RED WIRE
Go to component -> Manual a/c circuit, dual a/c circuit with rear cooler (2 of 2) -> REAR BLOWER UNIT
Wiring diagram rear blower unit (3 of 3)
2 3 4 5 6 7 8 9 GND
A/C COMPRESSOR CLUTCH RELAY
AIR MIXING DAMPER CONTROL MOTOR, POTENTIOMETER
BLK WIRE
BLK/YEL WIRE
BLOWER MOTOR
BLOWER RESISTOR
BLOWER SWITCH
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
CONDENSER FAN CONTROL RELAY
CONDENSER FAN MOTOR
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
FENDER PANEL)
FRONT REAR FAN CONTROL SWITCH
FUSE 10
FUSE 11
FUSE 19
GRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
HI LO
HOT AT ALL TIMES
ILLUM
JOINT CONNECTOR 1 (LEFT SIDE OF ENGINE COMPT)
JOINT CONNECTOR 2
JOINT CONNECTOR 3 (LEFT SIDE OF ENGINE COMPT)
JUNCTION BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
LT GRN WIRE
LT GRN/RED WIRE
MOTOR
OFF
ON OFF
ORG/ WIRE
PNK WIRE
PWR SOURCE MOTOR SIGNAL GND
REAR BLOWER REAR
REAR BLOWER UNIT
REAR FAN SWITCH
REAR HEATER CONTROL UNIT (ON BOTTOM OF HVAC ASSEMBLY)
REAR HEATER SWITCH
REAR HEATER UNIT
RED WIRE
RED/YEL WIRE
TEMPERATURE SWITCH
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Manual a/c circuit, dual a/c circuit with rear heater (2 of 2) -> REAR BLOWER UNIT
