Mitsubishi Montero III (1999-2006) power window sub switch door lock switch Wiring diagram
This page shows the only wiring diagram for the component.power window sub switch door lock switch, which is found in the car Mitsubishi Montero III (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power window sub switch door lock switch (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
DATA LINK CONNECTOR 1 (UNDER LEFT SIDE OF DASH, NEAR RELAY BOX)
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
ETACS-ECU
FROM ETACS ECU (JUNCTION BLOCK) (DIAGRAM 1 OF 2)
FUSE 5
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
HAZARD WARNING RELAY (BEHIND RIGHT SIDE OF GLOVE BOX)
HOT AT ALL TIMES
HOT IN ACC
JOINT CONNECTOR 1 (BEHIND UPPER RIGHT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 2
KEYLESS ENTRY RECEIVER ECU (IN LEFT SIDE OF LUGGAGE COMPT)
LEFT DOOR LOCK KEY CYLINDER SWITCH
LIFTGATE LOCK KEY CYLINDER SWITCH
LOCK
LOCK UNLOCK
MULTI- PURPOSE FUSE 2
NCA WIRE
POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH)
POWER WINDOW SUB SWITCH DOOR LOCK SWITCH
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT DOOR LOCK KEY CYLINDER SWITCH
UNLOCK
Go to component -> Power door locks circuit, with keyless entry (2 of 2) -> POWER WINDOW SUB SWITCH DOOR LOCK SWITCH
