Mitsubishi Montero III (1999-2006) power tops system anti-theft, horns, door locks systems Wiring diagram
This page shows the only wiring diagram for the component.power tops system anti-theft, horns, door locks systems, which is found in the car Mitsubishi Montero III (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power tops system anti-theft, horns, door locks systems (1 of 1)
A/C RELAY BOX
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT, DOOR LOCKS SYSTEMS
ANTI-THEFT, HEADLIGHTS SYSTEMS
BATTERY
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/WHT WIRE
DEFOGGER RELAY (BEHIND RIGHT SIDE OF GLOVE BOX)
DEFOGGER SYSTEM
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
ENGINE CONTROLS, TRANSMISSIONS, ANTI-THEFT SYSTEMS
EXTERIOR LIGHTS, DOOR LOCKS SYSTEMS
FROM ENGINE COMPARTMENT RELAY BOX (FUSIBLE LINK 8) (DIAGRAM 1 OF 2)
FUSE 1
FUSE 13
FUSE 14 FUSE 10
FUSE 15 FUSE 16
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 9
FUSIBLE LINK 10
FUSIBLE LINK 11
FUSIBLE LINK 12
FUSIBLE LINK 13
FUSIBLE LINK 14
FUSIBLE LINK 17
FUSIBLE LINK 6
FUSIBLE LINK 7
FUSIBLE LINK 8
FUSIBLE LINK 9
GRN/WHT WIRE
HEADLIGHT RELAY
HEADLIGHTS SYSTEM
IOD OR STORAGE CONNECTOR
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
PASSENGER COMPARTMENT RELAY BOX (BEHIND LEFT SIDE OF DASH) FUSE 18
POWER TOPS SYSTEM ANTI-THEFT, HORNS, DOOR LOCKS SYSTEMS
POWER WINDOWS, POWER TOPS SYSTEMS
RED WIRE
RED/BLK WIRE
RED/BLU (OR RED/YEL) WIRE
RED/WHT WIRE
STARTING/ CHARGING SYSTEM
STARTING/ CHARGING, ENGINE CONTROLS SYSTEMS
TO ENGINE COMPARTMENT RELAY BOX (FUSE 19) (DIAGRAM 2 OF 2)
TO ENGINE COMPARTMENT RELAY BOX (FUSE 20) (DIAGRAM 2 OF 2)
TO IGNITION SWITCH (DIAGRAM 2 OF 2)
TO JUNCTION BLOCK (FUSE 3)
TRANSMISSIONS SYSTEM
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 2) -> POWER TOPS SYSTEM ANTI-THEFT, HORNS, DOOR LOCKS SYSTEMS
