Mitsubishi Montero III (1999-2006) power distribution, air conditioning, exterior lights, seats systems Wiring diagrams

This page contains all the electrical diagrams for the component. power distribution, air conditioning, exterior lights, seats systems, in which he is found in the car Mitsubishi Montero III (1999-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram power distribution, air conditioning, exterior lights, seats systems (1 of 2)

Wiring diagram power distribution, air conditioning, exterior lights, seats systems for Mitsubishi Montero III (1999-2006) (1 of 2)

Get access

1 1 LIFTGATE SWITCH BLK WIRE CARGO SPACE LIGHT ROOM OFF ON COLUMN SWITCH (LIGHTING SWITCH) DEDICATED FUSE 1 DEDICATED FUSE 4 DOME LIGHT ROOM OFF ON DOOR IND COMBINATION METER ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL) ETACS-ECU GLOVE BOX LIGHT GLOVE BOX LIGHT SWITCH GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE HEAD OFF TAIL HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER, EXTERIOR LIGHTS, HEADLIGHTS SYSTEMS IOD OR STORAGE CONNECTOR (IN ENGINE COMPARTMENT RELAY BOX) JOINT CONNECTOR 3 JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) KEY REMINDER SWITCH IGNITION KEY HOLE ILLUMINATION LIGHT LEFT DOOR LIGHT LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LEFT VANITY MIRROR LIGHT MAP LIGHT MAP LIGHT (PART OF SUNROOF SWITCH) MULTI- PURPOSE FUSE 8 NCA WIRE OFF ON OFF POWER DISTRIBUTION, AIR CONDITIONING, EXTERIOR LIGHTS, SEATS SYSTEMS POWER DISTRIBUTION, SOUND, DEFOGGER, EXTERIOR LIGHTS SYSTEMS RED WIRE RED/BLK WIRE RIGHT DOOR LIGHT RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH RIGHT VANITY MIRROR LIGHT SOUND, INSTRUMENT CLUSTER SYSTEMS W/ W/ SUNROOF SUNROOF W/0 W/0 SUNROOF SUNROOF WHT WIRE YEL WIRE

Go to component -> Courtesy lamps circuit, with keyless entry -> POWER DISTRIBUTION, AIR CONDITIONING, EXTERIOR LIGHTS, SEATS SYSTEMS

Wiring diagram power distribution, air conditioning, exterior lights, seats systems (2 of 2)

Wiring diagram power distribution, air conditioning, exterior lights, seats systems for Mitsubishi Montero III (1999-2006) (2 of 2)

Get access

1 1 RIGHT REAR DOOR SWITCH BLK WIRE CARGO SPACE LIGHT COLUMN SWITCH (LIGHTING SWITCH) DEDICATED FUSE 1 DEDICATED FUSE 4 DOME LIGHT DOOR IND COMBINATION METER ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL) ETACS-ECU GLOVE BOX LIGHT GLOVE BOX LIGHT SWITCH GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE HEAD OFF TAIL HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER, EXTERIOR LIGHTS, HEADLIGHTS SYSTEMS IOD OR STORAGE CONNECTOR (IN ENGINE COMPARTMENT RELAY BOX) JOINT CONNECTOR 3 JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) KEY REMINDER SWITCH IGNITION KEY HOLE ILLUMINATION LIGHT LEFT DOOR LIGHT LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LEFT VANITY MIRROR LIGHT LIFTGATE SWITCH MAP LIGHT MAP LIGHT (PART OF SUNROOF SWITCH) MULTI- PURPOSE FUSE 8 NCA WIRE OFF OFF DOOR ON OFF ON OFF DOOR POWER DISTRIBUTION, AIR CONDITIONING, EXTERIOR LIGHTS, SEATS SYSTEMS POWER DISTRIBUTION, SOUND, DEFOGGER, EXTERIOR LIGHTS SYSTEMS RED WIRE RED/BLK WIRE RIGHT DOOR LIGHT RIGHT FRONT DOOR SWITCH RIGHT VANITY MIRROR LIGHT SOUND, INSTRUMENT CLUSTER SYSTEMS W/ SUNROOF W/O SUNROOF WHT WIRE YEL WIRE

Go to component -> Courtesy lamps circuit, without keyless entry -> POWER DISTRIBUTION, AIR CONDITIONING, EXTERIOR LIGHTS, SEATS SYSTEMS
