Mitsubishi Montero III (1999-2006) lumbar support switch Wiring diagram
This page shows the only wiring diagram for the component.lumbar support switch, which is found in the car Mitsubishi Montero III (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lumbar support switch (1 of 1)
BLK WIRE
BLU WIRE
DRIVER'S SIDE POWER SEAT ASSEMBLY
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FR RR
FRONT HEIGHT
FRONT HEIGHT MOTOR
FUSIBLE LINK 4
HOT AT ALL TIMES
LUMBAR SUPPORT MOTOR
LUMBAR SUPPORT SWITCH
NCA WIRE
POWER SEAT SWITCH
REAR HEIGHT
REAR HEIGHT MOTOR
RECLINING
RECLINING MOTOR
SLIDE
SLIDE MOTOR
UP DN
UP RR
Go to component -> Driver seat circuit -> LUMBAR SUPPORT SWITCH
