Mitsubishi Montero III (1999-2006) low, reverse reduc- tion tcc Wiring diagram
This page shows the only wiring diagram for the component.low, reverse reduc- tion tcc, which is found in the car Mitsubishi Montero III (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low, reverse reduc- tion tcc (1 of 1)
8 5 6 (UNDER RIGHT FRONT KICK PANEL)
A/T CONTROL SOLENOID VALVE ASSEMBLY (ON TRANSMISSION VALVE BODY ASSEMBLY)
A/T FLUID TEMPERATURE SENSOR
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/YEL WIRE
COMBINATION METER
CRUISE CONTROL SYSTEM
DEDICATED FUSE 14
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
J/C
J/C 4 (BEHIND RIGHT SIDE OF DASH)
J/C 5 (BEHIND LEFT SIDE OF DASH)
LOW, REVERSE REDUC- TION TCC
ORG/ WIRE
OVER- DRIVE UNDER- DRIVE SECOND
PARK/NEUTRAL POSITION SWITCH
PNK WIRE
POWERTRAIN CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
TRANSFER ECU (BEHIND CENTER OF DASH)
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 3.8l (5 of 5) -> LOW, REVERSE REDUC- TION TCC
