Mitsubishi Montero III (1999-2006) liftgate lock key cylinder switch Wiring diagrams
This page contains all the electrical diagrams for the component. liftgate lock key cylinder switch, in which he is found in the car Mitsubishi Montero III (1999-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram liftgate lock key cylinder switch (1 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
DATA LINK CONNECTOR 1 (UNDER LEFT SIDE OF DASH, NEAR RELAY BOX)
DIODE (THEFT ALARM HORN CIRCUIT) (LEFT END OF DASH)
DOOR LOCKS SYSTEM
DOOR LOCKS, INTERIOR LIGHTS SYSTEM
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
ETACS-ECU
FUSE 1
FUSE 3
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
HEADLIGHTS SYSTEM
HOOD SWITCH JOINT CONNECTOR 5 (BEHIND UPPER RIGHT SIDE OF DASH)
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN RUN OR START
IND SECURITY INDICATOR
IOD OR STORAGE CONNECTOR
JOINT CONNECTOR 1 (BEHIND UPPER RIGHT SIDE OF DASH)
JOINT CONNECTOR 2 (BEHIND UPPER RIGHT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEY REMINDER SWITCH (CLOSED WHEN KEY IS REMOVED)
LEFT DOOR LOCK KEY CYLINDER SWITCH
LEFT FRONT DOOR LOCK ACTUATOR (REAR OF LEFT FRONT DOOR)
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR LOCK ACTUATOR (REAR OF LEFT REAR DOOR) LOCK
LIFTGATE LOCK KEY CYLINDER SWITCH
LIFTGATE SWITCH
LOCK
LOCK OFF UNLOCK
MULTI- PURPOSE FUSE 8
NCA WIRE
OFF
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT DOOR LOCK KEY CYLINDER SWITCH
RIGHT FRONT DOOR LOCK ACTUATOR (REAR OF RIGHT FRONT DOOR) LOCK
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR LOCK ACTUATOR (REAR OF RIGHT REAR DOOR) LOCK
RIGHT REAR DOOR SWITCH LEFT REAR DOOR SWITCH
THEFT ALARM HORN RELAY (BEHIND RIGHT SIDE OF GLOVE BOX)
THEFT- ALARM HORN
UNLOCK
W/ KEYLESS ENTRY
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Forced entry circuit -> LIFTGATE LOCK KEY CYLINDER SWITCH
Wiring diagram liftgate lock key cylinder switch (2 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
DATA LINK CONNECTOR 1 (UNDER LEFT SIDE OF DASH, NEAR RELAY BOX)
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
ETACS-ECU
FROM ETACS ECU (JUNCTION BLOCK) (DIAGRAM 1 OF 2)
FUSE 5
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
HAZARD WARNING RELAY (BEHIND RIGHT SIDE OF GLOVE BOX)
HOT AT ALL TIMES
HOT IN ACC
JOINT CONNECTOR 1 (BEHIND UPPER RIGHT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 2
KEYLESS ENTRY RECEIVER ECU (IN LEFT SIDE OF LUGGAGE COMPT)
LEFT DOOR LOCK KEY CYLINDER SWITCH
LIFTGATE LOCK KEY CYLINDER SWITCH
LOCK
LOCK UNLOCK
MULTI- PURPOSE FUSE 2
NCA WIRE
POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH)
POWER WINDOW SUB SWITCH DOOR LOCK SWITCH
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT DOOR LOCK KEY CYLINDER SWITCH
UNLOCK
Go to component -> Power door locks circuit, with keyless entry (2 of 2) -> LIFTGATE LOCK KEY CYLINDER SWITCH
