Mitsubishi Montero III (1999-2006) joint connector 6 (behind left side Wiring diagram
This page shows the only wiring diagram for the component.joint connector 6 (behind left side, which is found in the car Mitsubishi Montero III (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram joint connector 6 (behind left side (1 of 1)
4 4 GROUND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COLUMN ECU
COLUMN SWITCH (AT TOP OF STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
DEDICATED FUSE 18
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
ETACS-ECU
GRN WIRE
GRN/ORG WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
JOINT CONNECTOR 4
JOINT CONNECTOR 6 (BEHIND LEFT SIDE
JOINT CONNECTOR 7 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
LT GRN WIRE
MULTI- PURPOSE FUSE 1
MULTI- PURPOSE FUSE 8
MULTI-PURPOSE FUSE 6
NCA WIRE
OF DASH)
OF TRANSMISSION)
OFF
OFF REAR WASHER RELAY
PNK 31 23 WIRE
PNK WIRE
REAR WASHER MOTOR (IN BACK DOOR)
REAR WASHER SWITCH ON
REAR WIPER MOTOR (IN BACK DOOR)
REAR WIPER RELAY
REAR WIPER SWITCH ON
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RV METER
TRANSMISSION RANGE SWITCH (LEFT SIDE
TRANSMISSIONS SYSTEM
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Rear wiper/washer circuit -> JOINT CONNECTOR 6 (BEHIND LEFT SIDE
