Mitsubishi Montero III (1999-2006) hot in start or on Wiring diagram
This page shows the only wiring diagram for the component.hot in start or on, which is found in the car Mitsubishi Montero III (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in start or on (1 of 1)
ANTENNA MOTOR ECU (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
DEDICATED FUSE 1
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN START OR ON
I C
IOD OR STORAGE CONNECTOR
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) MULTI- PURPOSE FUSE 8
MOTOR ANTENNA (REAR OF RIGHT FRONT WHEELWELL)
MULTI- PURPOSE FUSE 2
NCA WIRE
RADIO, TAPE PLAYER, CD PLAYER
RED WIRE
RED/BLK WIRE
WHT/BLK WIRE
Go to component -> Power antenna circuit -> HOT IN START OR ON
