Mitsubishi Montero III (1999-2006) fuse 10 Wiring diagrams

This page contains all the electrical diagrams for the component. fuse 10, in which he is found in the car Mitsubishi Montero III (1999-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

fuse 10 wiring diagram (1 of 6)

12 13 PNK WIRE A/C COMPRESSOR CLUTCH RELAY A/C SENSOR AIR MIXING DAMPER CONTROL MOTOR, POTENTIOMETER BETWEEN RELAY BOX, FENDER PANEL) BLK WIRE BLK/YEL WIRE BLOWER MOTOR BLOWER RESISTOR BLOWER SWITCH BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE CONDENSER FAN CONTROL RELAY CONDENSER FAN MOTOR ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT) FUSE 10 FUSE 11 FUSE 18 FUSE 19 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY/BLU WIRE HI LO HIGH- PRESSURE SIDE HOT AT ALL TIMES ILLUM JOINT CONNECTOR 1 JOINT CONNECTOR 2 JOINT CONNECTOR 3 (LEFT SIDE OF ENGINE COMPT) JOINT CONNECTOR 7 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (BEHIND LOWER LEFT SIDE OF DASH) LOW- PRESSURE SIDE LT GRN WIRE LT GRN/RED WIRE MAGNETIC VALVE MODE SELECTION DAMPER CONTROL MOTOR MOTOR DRIVER CIRCUIT OFF OFF ON ON OFF ORG/ WIRE PNK WIRE REAR A/C CONTROL UNIT (ON BOTTOM OF HVAC ASSEMBLY) REAR A/C SWITCH REAR A/C UNIT REAR BLOWER RELAY REAR FAN CONTROL SWITCH (FRONT) REAR FAN SWITCH RED WIRE RED/BLK WIRE RED/YEL WIRE SOLID STATE TEMPERATURE SWITCH VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/VIO WIRE

Go to component -> Automatic a/c circuit, with rear a/c (2 of 2) -> FUSE 10

fuse 10 wiring diagram (2 of 6)

12 13 PNK WIRE 2 3 4 5 6 7 8 9 10 11 12 13 14 GND A/C COMPRESSOR CLUTCH RELAY AIR CONDITIONING SENSOR BLK WIRE BLK/YEL WIRE BLOWER MOTOR BLOWER RESISTOR BLOWER SWITCH BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE CONDENSER FAN CONTROL RELAY CONDENSER FAN MOTOR DUAL PRESSURE SWITCH (AT LOWER LEFT SIDE OF A/C CONDENSER, ON LIQUID LINE) ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) FUSE 10 FUSE 11 FUSE 18 FUSE 19 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLU WIRE HI LO HIGH- PRESSURE SIDE HOT AT ALL TIMES ILLUM JOINT CONNECTOR 1 (LEFT SIDE OF ENGINE COMPT) JOINT CONNECTOR 2 JOINT CONNECTOR 3 (LEFT SIDE OF ENGINE COMPT) JOINT CONNECTOR 7 (BEHIND LEFT SIDE OF DASH) JOINT CONNECTOR 8 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (BEHIND LOWER LEFT SIDE OF DASH) LOW- PRESSURE SIDE LT GRN WIRE LT GRN/RED WIRE MAGNETIC VALVE OFF OFF ON ON OFF ORG/ WIRE PNK WIRE POWER REAR BLOWER RELAY REAR BLOWER UNIT REAR COOLER CONTROL UNIT (ON BOTTOM OF HVAC ASSEMBLY) REAR COOLER SWITCH REAR COOLER UNIT REAR FAN CONTROL SWITCH (FRONT) RED WIRE RED/BLK WIRE RED/YEL WIRE SOLID STATE TEMPERATURE SWITCH VIO WIRE VIO/WHT WIRE WHT WIRE WHT/RED WIRE YEL WIRE YEL/VIO WIRE

Go to component -> Automatic a/c circuit, with rear cooler (2 of 2) -> FUSE 10

fuse 10 wiring diagram (3 of 6)

12 13 14 SIG A/C COMPRESSOR CLUTCH RELAY AIR CONDITIONING SENSOR AIR MIXING DAMPER CONTROL MOTOR AND POTENTIOMETER BLK WIRE BLK/YEL WIRE BLOWER MOTOR BLOWER RESISTOR BLOWER SWITCH BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE CONDENSER FAN CONTROL RELAY CONDENSER FAN MOTOR ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT) FENDER PANEL) FUSE 10 FUSE 11 FUSE 19 GND SIG GRN WIRE GRN/WHT WIRE GRY/BLU WIRE HI LO HOT AT ALL TIMES ILLUM JOINT CONNECTOR 1 (LEFT SIDE OF ENGINE COMPT) JOINT CONNECTOR 2 JOINT CONNECTOR 3 (LEFT SIDE OF ENGINE COMPT) LT GRN WIRE LT GRN/RED WIRE MAGNETIC VALVE MODE SELECTION DAMPER CONTROL MOTOR MOTOR MOTOR DRIVE CIRCUIT OFF ON OFF ORG/ WIRE PNK WIRE PWR MOTOR SIG GND REAR A/C CONTROL UNIT (ON BOTTOM OF HVAC ASSEMBLY) REAR A/C SWITCH REAR A/C UNIT REAR BLOWER REAR (ON JUNCTION BLOCK) REAR FAN CONTROL SWITCH (FRONT) REAR FAN SWITCH RED WIRE RED/YEL WIRE TEMPERATURE SWITCH VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE

Go to component -> Manual a/c circuit, dual a/c circuit with rear a/c (2 of 2) -> FUSE 10

fuse 10 wiring diagram (4 of 6)

2 3 4 5 6 7 8 9 GND A/C COMPRESSOR CLUTCH RELAY AIR CONDITIONING SENSOR BLK WIRE BLK/YEL WIRE BLOWER MOTOR BLOWER RESISTOR BLOWER SWITCH BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE CONDENSER FAN CONTROL RELAY CONDENSER FAN MOTOR ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT) FENDER PANEL) FUSE 10 FUSE 11 FUSE 19 GRN/WHT WIRE GRN/YEL WIRE GRY/BLU WIRE HI LO HOT AT ALL TIMES ILLUM JOINT CONNECTOR 1 (LEFT SIDE OF ENGINE COMPT) JOINT CONNECTOR 2 JOINT CONNECTOR 3 (LEFT SIDE OF ENGINE COMPT) JUNCTION BLOCK (BEHIND LOWER LEFT SIDE OF DASH) LT GRN WIRE LT GRN/RED WIRE MAGNETIC VALVE ON OFF ORG/ WIRE PNK GND WIRE PNK WIRE PWR SOURCE REAR BLOWER RELAY REAR BLOWER UNIT REAR COOLER CONTROL UNIT (ON BOTTOM OF HVAC ASSEMBLY) REAR COOLER SWITCH REAR COOLER UNIT REAR FAN CONTROL SWITCH (FRONT) REAR FAN SWITCH RED WIRE RED/YEL WIRE TEMPERATURE SWITCH VIO WIRE VIO/WHT WIRE WHT WIRE WHT/RED WIRE

Go to component -> Manual a/c circuit, dual a/c circuit with rear cooler (2 of 2) -> FUSE 10

fuse 10 wiring diagram (5 of 6)

2 3 4 5 6 7 8 9 GND A/C COMPRESSOR CLUTCH RELAY AIR MIXING DAMPER CONTROL MOTOR, POTENTIOMETER BLK WIRE BLK/YEL WIRE BLOWER MOTOR BLOWER RESISTOR BLOWER SWITCH BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE CONDENSER FAN CONTROL RELAY CONDENSER FAN MOTOR ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT) FENDER PANEL) FRONT REAR FAN CONTROL SWITCH FUSE 10 FUSE 11 FUSE 19 GRN WIRE GRN/WHT WIRE GRY/BLU WIRE HI LO HOT AT ALL TIMES ILLUM JOINT CONNECTOR 1 (LEFT SIDE OF ENGINE COMPT) JOINT CONNECTOR 2 JOINT CONNECTOR 3 (LEFT SIDE OF ENGINE COMPT) JUNCTION BLOCK (BEHIND LOWER LEFT SIDE OF DASH) LT GRN WIRE LT GRN/RED WIRE MOTOR OFF ON OFF ORG/ WIRE PNK WIRE PWR SOURCE MOTOR SIGNAL GND REAR BLOWER REAR REAR BLOWER UNIT REAR FAN SWITCH REAR HEATER CONTROL UNIT (ON BOTTOM OF HVAC ASSEMBLY) REAR HEATER SWITCH REAR HEATER UNIT RED WIRE RED/YEL WIRE TEMPERATURE SWITCH VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE

Go to component -> Manual a/c circuit, dual a/c circuit with rear heater (2 of 2) -> FUSE 10

fuse 10 wiring diagram (6 of 6)

A/C COMPRESSOR CLUTCH RELAY BLK WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE CONDENSER FAN CONTROL RELAY DEF DEFROSTER SWITCH DUAL PRESSURE SWITCH (AT LOWER LEFT SIDE OF A/C CONDENSER, ON LIQUID LINE) ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF CYLINDER HEAD) FOOT FUSE 10 FUSE 19 GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRY/RED WIRE HIGH- PRESSURE SIDE HOT AT ALL TIMES JOINT CONNECTOR 2 JOINT CONNECTOR 3 (LEFT SIDE OF ENGINE COMPT) JOINT CONNECTOR 6 (BEHIND LEFT SIDE OF DASH) JOINT CONNECTOR 8 (BEHIND LEFT SIDE OF DASH) LOW- PRESSURE SIDE LT GRN/RED WIRE OFF OFF ON ORG/ WIRE OUTSIDE/INSIDE AIR SELECTION DAMPER CONTROL MOTOR (BELOW RIGHT SIDE OF DASH) POWERTRAIN CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH) RED WIRE RED/YEL WIRE VIO WIRE WHT/GRN WIRE YEL WIRE YEL/GRN WIRE YEL/VIO WIRE

Go to component -> Manual a/c circuit, single a/c circuit (2 of 2) -> FUSE 10
