Mitsubishi Montero III (1999-2006) front rear fan control switch Wiring diagram
This page shows the only wiring diagram for the component.front rear fan control switch, which is found in the car Mitsubishi Montero III (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front rear fan control switch (1 of 1)
2 3 4 5 6 7 8 9 GND
A/C COMPRESSOR CLUTCH RELAY
AIR MIXING DAMPER CONTROL MOTOR, POTENTIOMETER
BLK WIRE
BLK/YEL WIRE
BLOWER MOTOR
BLOWER RESISTOR
BLOWER SWITCH
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
CONDENSER FAN CONTROL RELAY
CONDENSER FAN MOTOR
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
FENDER PANEL)
FRONT REAR FAN CONTROL SWITCH
FUSE 10
FUSE 11
FUSE 19
GRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
HI LO
HOT AT ALL TIMES
ILLUM
JOINT CONNECTOR 1 (LEFT SIDE OF ENGINE COMPT)
JOINT CONNECTOR 2
JOINT CONNECTOR 3 (LEFT SIDE OF ENGINE COMPT)
JUNCTION BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
LT GRN WIRE
LT GRN/RED WIRE
MOTOR
OFF
ON OFF
ORG/ WIRE
PNK WIRE
PWR SOURCE MOTOR SIGNAL GND
REAR BLOWER REAR
REAR BLOWER UNIT
REAR FAN SWITCH
REAR HEATER CONTROL UNIT (ON BOTTOM OF HVAC ASSEMBLY)
REAR HEATER SWITCH
REAR HEATER UNIT
RED WIRE
RED/YEL WIRE
TEMPERATURE SWITCH
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Manual a/c circuit, dual a/c circuit with rear heater (2 of 2) -> FRONT REAR FAN CONTROL SWITCH
