Mitsubishi Montero III (1999-2006) dedicated fuse 28 Wiring diagrams
This page contains all the electrical diagrams for the component. dedicated fuse 28, in which he is found in the car Mitsubishi Montero III (1999-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
dedicated fuse 28 wiring diagram (1 of 2)
1 2 3 9 4 PNK PASSING WIRE
BEAM IND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
COLUMN ECU
COLUMN SWITCH (AT TOP OF STEERING COLUMN)
COMBINATION METER
DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) 1 9
DEDICATED FUSE 18
DEDICATED FUSE 20
DEDICATED FUSE 25
DEDICATED FUSE 26
DEDICATED FUSE 27
DEDICATED FUSE 28
DIMMER
DIMMER, PASSING SWITCH
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
ETACS-ECU
FOG IND
FOGLIGHT RELAY
FOGLIGHT SWITCH
FRONT ECU
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/RED WIRE
HEADLIGHT RELAY (HI)
HEADLIGHT RELAY (LO)
HOT AT ALL TIMES
HOT IN HOT IN ON OR RUN
ILLUM
JOINT CONNECTOR 2 (LEFT SIDE OF ENGINE COMPARTMENT)
JOINT CONNECTOR 2 (LEFT SIDE OF ENGINE COMPT)
JOINT CONNECTOR 3 (LEFT SIDE OF ENGINE COMPT)
JOINT CONNECTOR 5 (BEHIND LEFT SIDE OF DASH)
JOINT CONNECTOR 7 (BEHIND LEFT SIDE OF DASH)
JOINT CONNECTOR 8 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
LEFT FOG LIGHT
LEFT FRONT DOOR SWITCH
LEFT HEADLIGHT
LIGHTING SWITCH (HEAD)
MULTI- PURPOSE FUSE 10
MULTI- PURPOSE FUSE 6 MULTI-PURPOSE FUSE 5
PNK PNK WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT
SOLID STATE
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlights circuit -> DEDICATED FUSE 28
dedicated fuse 28 wiring diagram (2 of 2)
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT, DOOR LOCKS SYSTEMS
ANTI-THEFT, DOOR LOCKS, HORNS SYSTEM
ANTI-THEFT, ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
ANTI-THEFT, EXTERIOR LIGHTS, HEADLIGHTS, WIPER/ WASHER SYSTEMS
ANTI-THEFT, HEADLIGHTS SYSTEMS
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
DEDI- CATED FUSE 10 DEDI- CATED FUSE 19
DEDI- CATED FUSE 11 FUSIBLE LINK 2
DEDI- CATED FUSE 12
DEDI- CATED FUSE 29
DEDI- CATED FUSE 6
DEDI- CATED FUSE 8
DEDICATED FUSE 13
DEDICATED FUSE 14 DEDICATED FUSE 15
DEDICATED FUSE 16
DEDICATED FUSE 18
DEDICATED FUSE 19
DEDICATED FUSE 20 DEDICATED FUSE 27
DEDICATED FUSE 23
DEDICATED FUSE 24
DEDICATED FUSE 26 DEDICATED FUSE 25
DEDICATED FUSE 28
DOOR LOCKS, EXTERIOR LIGHTS SYSTEMS
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE CONTROLS SYSTEM
EXTERIOR LIGHTS, HEADLIGHTS SYSTEMS
FOG LIGHT RELAY
FRONT ECU
FUSIBLE LINK 1
FUSIBLE LINK 31 FUSIBLE LINK 32
FUSIBLE LINK 4
FUSIBLE LINK 5
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM (FOG LIGHT)
JUNCTION BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
LT GRN WIRE
ORG/ WIRE
ORG/BLU WIRE
POWER WINDOWS, SEATS SYSTEMS
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SOUND SYSTEMS
STARTING/ CHARGING SYSTEM
TO ACCESSORY SOCKET RELAY (DIAGRAM 3 OF 3)
TO DEDICATED FUSE 22 (DIAGRAM 3 OF 3)
TO FUSIBLE LINK 3 (DIAGRAM 2 OF 3)
TO INSTRUMENT CLUSTER SYSTEM (DIAGRAM 3 OF 3)
TO INTERIOR LIGHTS SYSTEM (DIAGRAM 3 OF 3)
TO MULTI- PURPOSE FUSE 11 (DIAGRAM 2 OF 3) POWER TOPS SYSTEM
TO MULTI- PURPOSE FUSE 5 (DIAGRAM 2 OF 3)
TRANSMISSIONS SYSTEM
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> DEDICATED FUSE 28
