Mitsubishi Montero III (1999-2006) dedicated fuse 15 Wiring diagram
This page shows the only wiring diagram for the component.dedicated fuse 15, which is found in the car Mitsubishi Montero III (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dedicated fuse 15 (1 of 1)
A/C RELAY BOX
BLK WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
CONDENSER FAN MOTOR (IN LEFT FRONT OF ENGINE COMPT)
CONDENSER FAN MOTOR RELAY (IN A/C RELAY BOX)
DEDICATED FUSE 15
ENGINE COOLANT TEMPERATURE SENSOR (ON FRONT CENTER OF ENGINE, IN COOLANT OUTLET)
GRN WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN MULTI- PURPOSE FUSE 4
JOINT CONNECTOR 4
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
YEL WIRE
Go to component -> Cooling fan circuit -> DEDICATED FUSE 15
