Mitsubishi Montero II (1991-2000) Wiring diagram engine performance 3.5ls, california

A/C COMPRESSOR CLUTCH RELAY BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE CHECK ENGINE INDICATOR (MIL) ENGINE COMPART- MENT RELAY BOX ENGINE CONTROL MODULE (BEHIND RIGHT KICK PANEL) ENGINE CONTROL RELAY ENGINE SPEED DETECTION CONNECTOR (RIGHT SIDE OF FIREWALL) FUEL INJECTORS FUSE LINK 6 GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLU WIRE HOT AT ALL TIMES IGNITION COIL (TOP LEFT SIDE OF ENGINE) IGNITION POWER TRANSISTOR (TOP LEFT SIDE OF ENGINE) INSTRUMENT CLUSTER LT GRN/RED WIRE RED/BLU WIRE SPARK PLUGS 1, 4 SPARK PLUGS 2, 5 SPARK PLUGS 3, 6 TACH WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE

BLK WIRE BLK/BLU WIRE BLK/PNK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE CAPACITOR (TOP OF ENGINE) EGR SOLENOID (RIGHT REAR OF ENGINE COMPT) ENGINE COOLANT TEMPERATURE SENSOR (ON THERMOSTAT HOUSING) EVAPORATIVE EMISSION PURGE SOLENOID (ON FRONT OF ENGINE) EVAPORATIVE EMISSION VENTILATION SOLENOID (LEFT REAR OF ENGINE COMPT) FUEL PUMP FUEL PUMP CONTROL RELAY FUEL TANK DIFFERENTIAL PRESSURE SENSOR (TOP OF FUEL TANK) GRN/YEL WIRE HOT AT ALL TIMES IGNITION SWITCH J/C 2 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LOCK MULTI- PURPOSE FUSE 11 NCA WIRE PARK/NEUTRAL POSITION SWITCH (ON TRANSMISSION) RUN WIRE STARTER MOTOR WHT/BLU WIRE WHT/RED WIRE YEL/GRN WIRE

A/C COMPRESSOR CLUTCH RELAY ABS CONTROL UNIT ABS SYSTEM BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/YEL WIRE BRN WIRE CAMSHAFT POSITION SENSOR (BOTTOM OF LEFT CAMSHAFT GEAR) CRANKSHAFT POSITION SENSOR (ABOVE CRANKSHAFT GEAR) CRUISE CONTROL SYSTEM DATA LINK CONNECTOR (PARTIAL) DOOR LOCKS SYSTEM ELC-4 SPEED A/T CONTROL MODULE (BEHIND LEFT SIDE OF DASH) ENGINE CONTROL MODULE (BEHIND RIGHT KICK PANEL) GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/YEL WIRE HOT AT ALL TIMES INSTRU- MENT CLUSTER IOD OR STORAGE CONNECTOR (IN ENGINE COMPARTMENT RELAY BOX) J/C 1 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) MANIFOLD DIFFERENTIAL PRESSURE SENSOR (TOP LEFT REAR OF ENGINE) MULTI-PURPOSE FUSE 19 NCA WIRE OPERATION DETECTION SWITCH ORG/ WIRE PNK WIRE POWER STEERING OIL PRESSURE SWITCH (ON POWER STEERING PUMP) RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE REED SWITCH (VSS) THROTTLE POSITION SENSOR (ON THROTTLE BODY) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE YEL/WHT WIRE
