Mitsubishi Montero II (1991-2000) turn- signal and hazard warning flasher unit wiring diagram
This page shows the only wiring diagram for the component.turn- signal and hazard warning flasher unit, which is found in the car Mitsubishi Montero II (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
turn- signal and hazard warning flasher unit wiring diagram (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
COLUMN SWITCH
COMBINATION METER
DEDICATED FUSE 1
DEDICATED FUSE 2
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD WARNING SWITCH
HEAD OFF TAIL
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUMINATION
JOINT CONNECTOR 3 (BEHIND LEFT SIDE OF DASH)
JOINT CONNECTOR 4 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT CLEARANCE LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT LICENSE PLATE LIGHT
LEFT SIDE MARKER LIGHT
LIGHTING SWITCH
MULTI- PURPOSE FUSE 3
OFF
ON OFF OFF
RED WIRE
RED/WHT WIRE
RH LH
RHEOSTAT
RIGHT CLEARANCE LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT SIDE MARKER LIGHT
SOLID STATE
TO LEFT REAR COMBINATION LIGHT (DIAGRAM 2 OF 2)
TO RIGHT REAR COMBINATION LIGHT (DIAGRAM 2 OF 2)
TURN
TURN SIGNAL LIGHT SWITCH
TURN- SIGNAL AND HAZARD WARNING FLASHER UNIT
Go to component -> Exterior lamps circuit (1 of 2) -> TURN- SIGNAL AND HAZARD WARNING FLASHER UNIT
