Mitsubishi Montero II (1991-2000) pwr ind Wiring diagram
This page shows the only wiring diagram for the component.pwr ind, which is found in the car Mitsubishi Montero II (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pwr ind (1 of 1)
2 IND
BEAM IND
BLK WIRE
BLK/ BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLK WIRE
CLOCK
COMBINATION METER
CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
CRUISE IND
D IND
DATA LINK CONNECTOR (BEHIND LEFT SIDE OF DASH)
DOOR IND
ELECTRONIC SUSPENSION SYSTEM (VARIABLE SHOCK ABSORBER CONTROL UNIT)
FUSE 4 (JUNCTION BLOCK)
FUSE 5 (RELAY BOX)
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOLD IND
ILLUM
ILLUM (4 BULBS)
INTERIOR LIGHTS SYSTEM (DOOR SWITCHES)
J/C 1 (BEHIND LEFT SIDE OF DASH)
L IND
L TURN IND
LT GRN WIRE
LT GRN/BLK WIRE
MULTI- METER
N IND
NCA WIRE
O/D OFF IND
OIL PRESSURE
OIL PRESSURE GAUGE UNIT (LOWER LEFT FRONT OF ENGINE)
OUTSIDE AIR TEMPERATURE SENSOR (BELOW LEFT HEADLIGHT)
OVERDRIVE SWITCH
P IND
PATTERN SELECT SWITCH
PWR IND
R IND
R TURN IND
REAR DIFFERENTIAL LOCK CONTROL UNIT (MOUNTED ON TOP OF LEFT REAR WHEELWELL)
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
SOLID STATE TEMPERATURE AND COMPASS DISPLAY
STARTING/ CHARGING SYSTEM (GENERATOR)
VOLTAGE
W/ ELECTRONIC COMPASS
W/O ELECTRONIC COMPASS
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Instrument cluster circuit (3 of 3) -> PWR IND
