Mitsubishi Montero II (1991-2000) pressure switch Wiring diagrams
This page contains all the electrical diagrams for the component. pressure switch, in which he is found in the car Mitsubishi Montero II (1991-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pressure switch (1 of 2)
ABS ECU (IN RIGHT REAR CORNER OF ENG COMPT)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/RED WIRE
BLU/YEL WIRE
COMBINATION METER
GRN/BLU WIRE
HOT IN RUN OR START
ILLUM- INATION LAMP
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
MULTI- PURPOSE FUSE 11
NCA WIRE
ON OFF
PRESSURE SWITCH
PUMP MOTOR
R/D LOCK INDICATOR
REAR DIFFERENTIAL LOCK AIR PUMP (ON UNDERSIDE OF VEHICLE, ON DIFFERENTIAL)
REAR DIFFERENTIAL LOCK DETECTION SWITCH (ON REAR DIFFERENTIAL HOUSING)
REAR DIFFERENTIAL LOCK ECU (ON RIGHT REAR QUARTER PANEL, BEHIND TRIM)
REAR DIFFERENTIAL LOCK SWITCH
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RELEASE VALVE
SWITCH (ON TRANSFER CASE)
TRANSMISSIONS
VEHICLE SPEED SENSOR (ON TRANSMISSION TAILSHAFT)
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Differential lock circuit -> PRESSURE SWITCH
Wiring diagram pressure switch (2 of 2)
24 C-04
4 C-05
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/RED WIRE
BLU/YEL WIRE
CIRCUIT
COMBINATION METER
D-06
DETECTION SWITCH (ON TRANSFER CASE)
FUSE 11
GRN/BLU WIRE
HOT IN RUN OR START
ILLUM
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
NCA WIRE
ON OFF
PRESSURE SWITCH
R/D LOCK
REAR DIFFERENTIAL LOCK AIR PUMP (ON DIFFERENTIAL)
REAR DIFFERENTIAL LOCK CONTROL UNIT (ON RIGHT REAR QUARTER PANEL, BEHIND TRIM)
REAR DIFFERENTIAL LOCK DETECTION SWITCH (ON DIFFERENTIAL)
REAR DIFFERENTIAL LOCK SWITCH
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RELEASE VALVE
VEHICLE SPEED SENSOR (ON TRANS- MISSION TILSHAFT)
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Rear differential lock circuit -> PRESSURE SWITCH
