Mitsubishi Montero II (1991-2000) hot in acc or run Wiring diagrams

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE CIRCUIT BREAKER COLUMN SWITCH HI OFF HOT IN ACC OR RUN INTERMITTENT WIPER RELAY JOINT CONNECTOR 5 (RIGHT SIDE OF DASH) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) MULTI- PURPOSE FUSE 9 NCA WIRE OFF OFF HI HI LO INT INT LO OFF LO INT SOLID STATE VARIABLE WIPER CONTROL SWITCH WIND- SHIELD WASHER SWITCH WIND- SHIELD WIPER SWITCH WINDSHIELD WASHER MOTOR (BOTTOM OF WINDSHIELD WASHER RESERVOIR) WINDSHIELD WIPER MOTOR (ON LEFT SIDE OF FIREWALL)

1998-99 BLK WIRE CLOCK- SPRING DEDICATED FUSE 9 ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE HORN (HI) HORN (LO) HORN RELAY (ON RIGHT REAR SIDE OF ENGINE COMPT) HORN SWITCH HOT IN ACC OR RUN

ANTENNA MOTOR ANTENNA MOTOR ECU (UNDER LEFT SIDE OF DASH) BLK WIRE BLU WIRE BRN WIRE DEDICATED FUSE 5 DOWN UP ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL) FUSE 11 FUSE 4 GRN/WHT WIRE HOT AT ALL TIMES HOT IN ACC OR RUN HOT IN RUN OR START IOD OR STORAGE CONNECTOR (IN ENG COMPT RELAY BOX) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) MULTI- PURPOSE RADIO, TAPE PLAYER RED WIRE RED/BLK WIRE SOLID STATE WHT WIRE WHT/BLK WIRE

1998-00 ANTENNA BACK DOOR SWITCH (IN BACK DOOR) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE CARGO SPACE LIGHT (REAR OF ROOF) DATA LINK CONNECTOR DOME LIGHT (CENTER OF ROOF) DOOR LOCK CONTROL UNIT (BEHIND LEFT SIDE OF DASH) DOOR LOCK RELAY (ON BRACKET, BEHIND LEFT SIDE OF DASH) UNLOCK OFF ON GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ACC OR RUN IOD OR STORAGE CONNECTOR (IN ENG COMPT RELAY BOX) J/C 2 (BEHIND LEFT SIDE OF DASH) J/C 3 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) KEY REMINDER SWITCH (LEFT SIDE OF DASH) KEYLESS ENTRY CONTROL UNIT (BEHIND RIGHT SIDE QUARTER PANEL) LEFT FRONT DOOR LOCK ACTUATOR LEFT FRONT DOOR SWITCH (LEFT FRONT DOOR) LEFT KEY SWITCH (LEFT FRONT DOOR) LEFT REAR DOOR SWITCH (LEFT REAR DOOR) RIGHT REAR DOOR SWITCH (RIGHT REAR DOOR) LOCK LOCK JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) OFF ON MULTI- PURPOSE FUSE 6 MULTI- PURPOSE FUSE 19 MULTI- PURPOSE FUSE 9 NCA WIRE ON OFF RED WIRE RED/ WHT WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR LOCK ACTUATOR LEFT REAR DOOR LOCK ACTUATOR RIGHT FRONT DOOR SWITCH (RIGHT FRONT DOOR) RIGHT KEY RIGHT REAR DOOR LOCK ACTUATOR BACK DOOR LOCK ACTUATOR SOLID STATE SPARE CONNECTOR (1999-00) SWITCH (RIGHT FRONT DOOR) UN LOCK UN- LOCK LOCK WHT/BLK WIRE YEL WIRE

BLK WIRE BLK/RED WIRE BLU WIRE BLU/WHT WIRE DEFOGGER SYSTEM DOWN GRN WIRE HOT IN ACC OR RUN HTR JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LEFT LEFT REMOTE CONTROLLED MIRROR LEFT RIGHT OFF MULTI- PURPOSE FUSE 8 RED WIRE REMOTE CONTROLLED MIRROR SWITCH RIGHT RIGHT OFF RIGHT REMOTE CONTROLLED MIRROR W/O MIRROR HEATER W/ MIRROR HEATER YEL WIRE

BLK WIRE BLU WIRE COLUMN SWITCH GRN WIRE HOT IN ACC OR RUN JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) MULTI- PURPOSE FUSE 9 NCA WIRE REAR INTERMITTENT WIPER RELAY (ON PASSENGER COMPARTMENT RELAY BOX) REAR WASHER MOTOR (IN RIGHT REAR OF VEHICLE) REAR WASHER SWITCH OFF LO ON REAR WIPER MOTOR (ON CENTER OF TAILGATE) REAR WIPER SWITCH OFF RED WIRE SOLID STATE
