Mitsubishi Montero II (1991-2000) dedicated fuse 12 Wiring diagrams
This page contains all the electrical diagrams for the component. dedicated fuse 12, in which he is found in the car Mitsubishi Montero II (1991-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dedicated fuse 12 (1 of 2)
1998, 1999
2.4L ENGINES ONLY
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
CHARGING SYSTEM (GENERATOR)
DEDICATED FUSE 12
DEFOGGER
DEFOGGER RELAY (BEHIND LEFT SIDE OF GLOVE BOX)
DEFOGGER SWITCH
DEFOGGER TIMER (ON PASSENGER COMPARTMENT RELAY BOX)
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL) DEDICATED FUSE 16
ENGINE CONTROLS SYSTEM (DIODE)
GRN/BLK WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN
ILLUM
IND
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT REMOTE CONTROLLED MIRROR
MIRROR HEATER
MULTI- PURPOSE FUSE 7
RED WIRE
RIGHT REMOTE CONTROLLED MIRROR
WHT WIRE
Go to component -> Defogger circuit -> DEDICATED FUSE 12
Wiring diagram dedicated fuse 12 (2 of 2)
2.4L 3.0L
3.0L
A/C RELAY BRACKET (ON LEFT INNER FENDER PANEL)
AIR CONDITIONIG SYSTEM
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
ANTI-LOCK BRAKES SYSTEM, CRUISE CONTROL SYSTEM, EXTERIOR LIGHTS SYSTEM
BATTERY
BLK/RED WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/WHT WIRE
DEDICATED FUSE 1
DEDICATED FUSE 12
DEDICATED FUSE 13
DEDICATED FUSE 2
DEDICATED FUSE 4
DEDICATED FUSE 5
DEDICATED FUSE 6
DEDICATED FUSE 7
DEDICATED FUSE 8
DEFOGGER SYSTEM
DEFOGGER SYSTEM, ENGINE CONTROLS SYSTEM, POWER TOPS SYSTEM
DOOR LOCKS SYSTEM
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
ENGINE CONTROLS SYSTEM
FUSIBLE LINK 1
FUSIBLE LINK 2
FUSIBLE LINK 3
FUSIBLE LINK 4
FUSIBLE LINK 5
FUSIBLE LINK 6
FUSIBLE LINK 7
FUSIBLE LINK 8
FUSIBLE LINK 9
HEADLIGHT RELAY
HEADLIGHTS SYSTEM
IOD OR STORAGE CONNECTOR
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
MULTI-PURPOSE FUSE 6
POWER WINDOWS SYSTEM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
STARTING/ CHARGING SYSTEM
STARTING/ CHARGING SYSTEM (A/T), ENGINE CONTROLS SYSTEM, CRUISE CONTROL SYSTEM
TO ENGINE COMPARTMENT RELAY BOX DEDICATED FUSE 14 (DIAGRAM 2 OF 2)
TO ENGINE COMPARTMENT RELAY BOX DEDICATED FUSE 15 (DIAGRAM 2 OF 2)
TO IGNITION SWITCH (DIAGRAM 2 OF 2)
TO JUNCTION BLOCK MULTI-PURPOSE FUSE 6
WHT WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 2) -> DEDICATED FUSE 12
