Mitsubishi Montero II (1991-2000) combination meter hi beam indicator Wiring diagram
This page shows the only wiring diagram for the component.combination meter hi beam indicator, which is found in the car Mitsubishi Montero II (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram combination meter hi beam indicator (1 of 1)
BLK WIRE
BLU WIRE
COLUMN SWITCH
COMBINATION METER HI BEAM INDICATOR
DIMMER, PASSING SWITCH
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL) DEDICATED FUSE 4
ENGINE CONTROLS
FUSIBLE LINK 3
HEAD
HEADLIGHT RELAY (IN ENGINE COMPARTMENT RELAY BOX)
HOT AT ALL TIMES
JOINT CONNECTOR 3 (BEHIND LEFT SIDE OF DASH)
LEFT HEADLIGHT HI
LIGHTING SWITCH
ON OFF
ON OFF OFF TAIL
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT HEADLIGHT HI
WHT WIRE
YEL WIRE
