Mitsubishi Montero II (1991-2000) anti-lock brakes system, cruise control system, exterior lights system Wiring diagram
This page shows the only wiring diagram for the component.anti-lock brakes system, cruise control system, exterior lights system, which is found in the car Mitsubishi Montero II (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram anti-lock brakes system, cruise control system, exterior lights system (1 of 1)
2.4L 3.0L
3.0L
A/C RELAY BRACKET (ON LEFT INNER FENDER PANEL)
AIR CONDITIONIG SYSTEM
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
ANTI-LOCK BRAKES SYSTEM, CRUISE CONTROL SYSTEM, EXTERIOR LIGHTS SYSTEM
BATTERY
BLK/RED WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/WHT WIRE
DEDICATED FUSE 1
DEDICATED FUSE 12
DEDICATED FUSE 13
DEDICATED FUSE 2
DEDICATED FUSE 4
DEDICATED FUSE 5
DEDICATED FUSE 6
DEDICATED FUSE 7
DEDICATED FUSE 8
DEFOGGER SYSTEM
DEFOGGER SYSTEM, ENGINE CONTROLS SYSTEM, POWER TOPS SYSTEM
DOOR LOCKS SYSTEM
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
ENGINE CONTROLS SYSTEM
FUSIBLE LINK 1
FUSIBLE LINK 2
FUSIBLE LINK 3
FUSIBLE LINK 4
FUSIBLE LINK 5
FUSIBLE LINK 6
FUSIBLE LINK 7
FUSIBLE LINK 8
FUSIBLE LINK 9
HEADLIGHT RELAY
HEADLIGHTS SYSTEM
IOD OR STORAGE CONNECTOR
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
MULTI-PURPOSE FUSE 6
POWER WINDOWS SYSTEM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
STARTING/ CHARGING SYSTEM
STARTING/ CHARGING SYSTEM (A/T), ENGINE CONTROLS SYSTEM, CRUISE CONTROL SYSTEM
TO ENGINE COMPARTMENT RELAY BOX DEDICATED FUSE 14 (DIAGRAM 2 OF 2)
TO ENGINE COMPARTMENT RELAY BOX DEDICATED FUSE 15 (DIAGRAM 2 OF 2)
TO IGNITION SWITCH (DIAGRAM 2 OF 2)
TO JUNCTION BLOCK MULTI-PURPOSE FUSE 6
WHT WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 2) -> ANTI-LOCK BRAKES SYSTEM, CRUISE CONTROL SYSTEM, EXTERIOR LIGHTS SYSTEM
