Mitsubishi Montero II (1991-2000) 25 18 1999 1997, 98 Wiring diagram
This page shows the only wiring diagram for the component.25 18 1999 1997, 98, which is found in the car Mitsubishi Montero II (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 25 18 1999 1997, 98 (1 of 1)
23 19 1999 1997, 98 JOINT CONNECTOR 3 (BEHIND LEFT SIDE OF DASH)
25 18 1999 1997, 98
8 D-06 8 D-01 1 5 D-13 10 D-14 16 4 D-13
BLK WIRE
BLK/WHT WIRE
C-04 60 C-02
COLUMN SWITCH
COMBINATION METER
D-11 OR D-12
DEDICATED FUSE 2
DEDICATED FUSE 5
ENGINE COMPARTMENT RELAY BOX (ON LEFT INNER FENDER PANEL)
ETACS-ECU OR TONE ALARM ECU
FRONT DOOR SWITCH
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEAD OFF TAIL
HOT AT ALL TIMES
HOT IN RUN OR START D-01
IOD OR STORAGE CONNECTOR (IN ENG COMPT RELAY BOX)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEY REMINDER SWITCH (SHOWN WITH IGNITION KEY REMOVED)
MULTI- PURPOSE FUSE 11
NCA WIRE
RED WIRE
SEAT BELT INDICATOR
SEAT BELT SWITCH (SHOWN WITH SEAT BELT UNBUCKLED)
WHT WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Warning system circuits -> 25 18 1999 1997, 98
