Mitsubishi Mirage VI facelift (2015-2020) right daytime running light Wiring diagram
This page shows the only wiring diagram for the component.right daytime running light, which is found in the car Mitsubishi Mirage VI facelift (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right daytime running light (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU/WHT WIRE
COLUMN ECU
COLUMN SWITCH (INTEGRAL TO COLUMN SWITCH ASSEMBLY)
CONTROL
DATA
DIMMER, PASSING SWITCH
FOG LIGHTING
FUSE 14
FUSIBLE LINK 5
FUSIBLE LINK BOX
GRN/WHT WIRE
GRY/BLK WIRE
HEAD
HEADLIGHT
HOT AT ALL TIMES
J/C 10 (C-10)
J/C 9 (C-109)
LEFT DAYTIME RUNNING LIGHT
LEFT FOG LIGHT
LIGHTING SWITCH
NCA WIRE
RED/WHT WIRE
RELAY BOX
RIGHT DAYTIME RUNNING LIGHT
RIGHT END OF DASH)
RIGHT FOG LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT ASSEMBLY
SWITCH
TAIL
UNIT)
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL/BLK WIRE
Go to component -> Headlights circuit (2 of 2) -> RIGHT DAYTIME RUNNING LIGHT
