Mitsubishi Mirage VI facelift (2015-2020) hot w/ mfi relay energized Wiring diagrams
This page contains all the electrical diagrams for the component. hot w/ mfi relay energized, in which he is found in the car Mitsubishi Mirage VI facelift (2015-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hot w/ mfi relay energized (1 of 2)
ANT
ANT+ C-416 ETACS-ECU
BLK WIRE
BLK/WHT WIRE
BLU WIRE
C-403
C-404
C-407
C-416
CAN TRANSCEIVER CIRCUIT
CANL C-228
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE
FUSE 15
FUSE 23
FUSE 26
GND C-407
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT W/ MFI RELAY ENERGIZED
IGNITION KEY
IGNITION KEY RING ANTENNA
J/C 7 (C-105)
JUNCTION BLOCK (LEFT END OF DASH)
KEY REMINDER SWITCH
LT GRN WIRE
NCA WIRE
PNK/BLK WIRE
POWER SUPPLY
RED WIRE
RELAY BOX
RIGHT END OF DASH)
VIO WIRE
WHT/BLK WIRE
Go to component -> Immobilizer circuit -> HOT W/ MFI RELAY ENERGIZED
