Mitsubishi Mirage VI facelift 2 (2019-2024) w/ safety power windows Wiring diagram
This page shows the only wiring diagram for the component.w/ safety power windows, which is found in the car Mitsubishi Mirage VI facelift 2 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ safety power windows (1 of 1)
ACCESSORY SOCKET
AUTO A/C CONTROLLER ASSEMBLY (A/C-ECU)
AUTOMATIC A/C
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR
BLOWER RELAY
C-08
C-09
C-208
C-226
C-228
C-23
C-403
C-404
C-407
C-416
C-42
C-43
CLUTCH INTERLOCK SWITCH
COLUMN SWITCH
COMBINATION METER
DRIVER'S SIDE LOCK/ UNLOCK SWITCH
ELECTRIC POWER STEERING ECU
ENGINE CONTROL MODULE
ETACS-ECU
F-04
GRY WIRE
HAZARD WARNING LIGHT SWITCH
HEATED SEAT RELAY
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
J/C 7 (C-105)
LEFT DOOR MIRROR ASSEMBLY MIRROR HEATER
LEFT FRONT DOOR LOCK ACTUATOR
LINEAR AIR-FUEL RATIO SENSOR SHIELD
M/T
MICROPHONE UNIT SHIELD
MULTI VISION DISPLAY
NCA WIRE
POWER TRANSISTOR
POWER WINDOW MAIN SWITCH
POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH)
RADIO, CD PLAYER
REMOTE CONTROLLED MIRROR SWITCH
RIGHT END OF DASH)
SMARTPHONE LINK DISPLAY AUDIO
TRANSAXLE CONTROL MODULE
W/ SAFETY POWER WINDOWS
W/O SAFETY POWER WINDOWS
YEL WIRE
Go to component -> Ground distribution circuit (2 of 3) -> W/ SAFETY POWER WINDOWS
