Mitsubishi Mirage VI facelift 2 (2019-2024) liftgate lock/unlock switch Wiring diagrams
This page contains all the electrical diagrams for the component. liftgate lock/unlock switch, in which he is found in the car Mitsubishi Mirage VI facelift 2 (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram liftgate lock/unlock switch (1 of 2)
18 C-124
ANTG
ANTP
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
C-124
C-131
C-22
C-404
COMPUTER DATA LINES SYSTEM
D-07
DRIVER'S SIDE LOCK/ UNLOCK SWITCH
DRIVER'S SIDE OUTSIDE TRANSMISSION ANTENNA ASSEMBLY
DRRQ
DRVB
EASG
EDRG
EDRP
EGTG C-132
EGTP
FRONT INSIDE TRANSMISSION ANTENNA ASSEMBLY
FUSE 13
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INFG
INFP PNK EASP WIRE
INRG
INRP
IOD
J/C 9 (C-109)
JUNCTION BLOCK
KEY SLOT
KOS, OSS-ECU
LEDA
LEDG
LEDW
LIFTGATE LOCK/UNLOCK SWITCH
LIFTGATE OUTSIDE TRANSMISSION ANTENNA ASSEMBLY
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OUTER TONE ALARM
PASSENGER'S SIDE OUTSIDE TRANSMISSION ANTENNA ASSEMBLY
PDSW
PNK GTRQ WIRE
PNK WIRE
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
REAR INSIDE TRANSMISSION ANTENNA ASSEMBLY
RED WIRE
RIGHT END OF DASH)
SGND
STARTING/CHARGING SYSTEM
STO
TAN WIRE
UHF RECEIVER
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit, w/ one touch start (1 of 3) -> LIFTGATE LOCK/UNLOCK SWITCH
