Mitsubishi Mirage VI facelift 2 (2019-2024) left door mirror assembly Wiring diagrams
This page contains all the electrical diagrams for the component. left door mirror assembly, in which he is found in the car Mitsubishi Mirage VI facelift 2 (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left door mirror assembly (1 of 3)
AUTO A/C CONTROLLER ASSEMBLY (A/C-ECU)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
C-12
C-22
C-403
C-416
C-419
COMPUTER DATA LINES SYSTEM
D-07
DFSW
ETACS-ECU
FUSE 16
FUSE 19
FUSE 22
G-02
G-11
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/C 18 (C-137)
J/C 7 (C-105) (RIGHT END OF DASH)
JUNCTION BLOCK
LEFT DOOR MIRROR ASSEMBLY
MIRROR HEATER
NCA WIRE
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
RED WIRE
RIGHT DOOR MIRROR ASSEMBLY
RLY
TAN WIRE
Go to component -> Defoggers circuit -> LEFT DOOR MIRROR ASSEMBLY
Wiring diagram left door mirror assembly (2 of 3)
BACKUP
BACKUP LAMPS CIRCUIT
BKLP
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN/WHT WIRE
C-118
C-12
C-131
C-211
C-212
C-22
C-405
C-406
C-407
C-416
C-418
D-07
ENGINE CONTROLS SYSTEM
ETACS-ECU
FIELD-EFFECT TRANSISTOR
FUSE 1
FUSE 12
FUSE 16
FUSE 7
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HIGH MOUNTED STOPLIGHT
HOT AT ALL TIMES
HOT AT ALL TIMES RELAY BOX
J/C 13 (D-11)
J/C 16 (D-42)
J/C 17 (D-41)
J/C 25 (D-43)
J/C 26 (C-236)
JUNCTION BLOCK
KOS, OSS-ECU
LEFT DOOR MIRROR ASSEMBLY
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT FRONT TURN SIGNAL LIGHT (HALOGEN)
LEFT LICENSE PLATE LIGHT
LEFT POSITION LIGHT
LEFT REAR COMBINATION LIGHT
LEFT SIDE TURN SIGNAL LIGHT (W/ FENDER PANEL)
LEFT TURN SIGNAL LIGHT
LT BLU WIRE
NCA WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/WHT WIRE
RIGHT DOOR MIRROR ASSEMBLY
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT POSITION LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT SIDE TURN SIGNAL LIGHT (W/ FENDER PANEL)
RIGHT TURN SIGNAL LIGHT
STOP
STOPLIGHT SWITCH
TAIL
TAIL LIGHT RELAY
TURN
VIO WIRE
W/ FCM
W/O FCM
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> LEFT DOOR MIRROR ASSEMBLY
Wiring diagram left door mirror assembly (3 of 3)
BLK WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
C-12
C-22
C-403
DEFOGGER SYSTEM
DOWN OPERATION SWITCH
FUSE 8
GRN WIRE
GRN/WHT WIRE
GRY/BLK WIRE
HORIZONTAL MOVEMENT MOTOR
HOT IN ON OR ACC
J/C 8 (C-107)
JUNCTION BLOCK
LEFT DOOR MIRROR ASSEMBLY
LEFT OFF
LEFT OPERATION SWITCH
LT BLU WIRE
MIRROR HEATER
NCA WIRE
PNK WIRE
REMOTE CONTROLLED MIRROR SWITCH
RIGHT
RIGHT DOOR MIRROR ASSEMBLY
RIGHT OPERATION SWITCH
UP OPERATION SWITCH
VERTICAL MOVEMENT MOTOR
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior power mirror circuit -> LEFT DOOR MIRROR ASSEMBLY
