Mitsubishi Mirage VI facelift 2 (2019-2024) horizontal movement motor Wiring diagram
This page shows the only wiring diagram for the component.horizontal movement motor, which is found in the car Mitsubishi Mirage VI facelift 2 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram horizontal movement motor (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
C-12
C-22
C-403
DEFOGGER SYSTEM
DOWN OPERATION SWITCH
FUSE 8
GRN WIRE
GRN/WHT WIRE
GRY/BLK WIRE
HORIZONTAL MOVEMENT MOTOR
HOT IN ON OR ACC
J/C 8 (C-107)
JUNCTION BLOCK
LEFT DOOR MIRROR ASSEMBLY
LEFT OFF
LEFT OPERATION SWITCH
LT BLU WIRE
MIRROR HEATER
NCA WIRE
PNK WIRE
REMOTE CONTROLLED MIRROR SWITCH
RIGHT
RIGHT DOOR MIRROR ASSEMBLY
RIGHT OPERATION SWITCH
UP OPERATION SWITCH
VERTICAL MOVEMENT MOTOR
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior power mirror circuit -> HORIZONTAL MOVEMENT MOTOR
