Mitsubishi Mirage VI facelift 2 (2019-2024) forward of battery) Wiring diagram
This page shows the only wiring diagram for the component.forward of battery), which is found in the car Mitsubishi Mirage VI facelift 2 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram forward of battery) (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
C-213
C-24
C-25
C-26
COME
COMPUTER DATA LINES SYSTEM
FORWARD OF BATTERY)
GRN WIRE
HOT AT ALL TIMES
J/C 2 (C-204)
LT BLU WIRE
NCA WIRE
PTC HEATER (IN HVAC UNIT)
PTC HEATER CONTROL UNIT
PTC HEATER RELAY 1
PTC HEATER RELAY 2
RED WIRE
RIGHT END OF DASH)
SUB RELAY BOX
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (3 of 3) -> FORWARD OF BATTERY)
