Mitsubishi Mirage VI facelift 2 (2019-2024) fcm fcm on off ind ind Wiring diagram
This page shows the only wiring diagram for the component.fcm fcm on off ind ind, which is found in the car Mitsubishi Mirage VI facelift 2 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fcm fcm on off ind ind (1 of 1)
ASC-ECU
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN/WHT WIRE
C-213
C-32
C-403
C-404
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FCM FCM ON OFF IND IND
FCM ON/OFF SWITCH
FCM/LDW/AHB-ECU
FCSW
FUSE 15
ILL
J/C 10 (C-10)
J/C 7 (C-106)
JUNCTION BLOCK
LDW IND ON IND
LDW READY
LDW SWITCH
LDWS
LED DRIVE
LT BLU WIRE
LT GRN WIRE
PNK/BLK WIRE
RED WIRE
RED/WHT WIRE
RELAY ENERGIZED
TAN WIRE
TRANSCEIVER CIRCUIT
VIO WIRE
WHT WIRE
YEL/BLK WIRE
Go to component -> Lane departure warning circuit -> FCM FCM ON OFF IND IND
