Instrument cluster circuit for Mitsubishi Mirage V (1995-2003)

A/T BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRAKE FLUID LEVEL SWITCH (LEFT REAR OF ENGINE COMPT, IN BRAKE FLUID RESERVOIR) DEDICATED FUSE 2 EXTERIOR LIGHTS SYSTEM (BACKUP LAMP) HOT AT ALL TIMES ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT) HOT IN ON OR START J/C 3 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (UNDER LEFT SIDE OF DASH, ABOVE KICK PANEL) JUNCTION BLOCK (UNDER LEFT SIDE OF DASH, ABOVE KICK PANEL) MULTI- PURPOSE FUSE 2 LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LT GRN/BLK WIRE M/T M/T ONLY MULTI- PURPOSE FUSE 4 OFF OFF ON ORG/ WIRE PARK/NEUTRAL POSITION SWITCH (IN LEFT SIDE OF ENGINE COMPT, ON TRANSAXLE) PARKING BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER) RED WIRE RED/BLK WIRE RED/BLU WIRE RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH VEHICLE SPEED SENSOR (LEF SIDE OF ENGINE COMPT, ON TRANSAXLE) YEL WIRE YEL/GRN WIRE YEL/RED WIRE

2 IND 3 IND ABS IND. ANTI-LOCK BRAKES SYSTEM AUTO-CRUISE CONTROL ECU (UNDER LEFT SIDE OF DASH) BEAM IND BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BLU/YEL WIRE BRAKE IND CHARGE IND CHECK ENGINE IND COMBINATION METER CRUISE IND D IND DOOR IND ENGINE CONTROLS SYSTEM FUEL GAUGE FUEL GAUGE UNIT (IN FUEL TANK) FUEL IND GENERATOR GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM ILLUMINATION L IND LEFT TURN IND LT GRN WIRE LT GRN/BLK WIRE N IND OFF OIL IND OIL PRESSURE SWITCH (LOWER FRONT OF ENGINE) ORG/ WIRE P IND R IND RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT TURN IND SEAT BELT IND SPEEDOMETER SRS IND SUPPLEMENTAL RESTRAINTS SYSTEM TACHOMETER TEMPERATURE GAUGE WARNING SYSTEMS INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
