Wiring diagram engine performance 1.5ls, with a/t for Mitsubishi Mirage V (1995-2003)

A/C SYSTEM BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE CAMSHAFT POSITION SENSOR DISTRIBUTOR DISTRIBUTOR ASSEMBLY ENGINE COMPART- MENT RELAY BOX ENGINE SPEED DETECTION CONNECTOR (ON TOP RIGHT OF FIREWALL) FUEL INJECTORS FUSIBLE LINK 7 GENERATOR GRN WIRE GRN/BLU WIRE GRN/WHT WIRE HOT AT ALL TIMES IDLE AIR CONTROL MOTOR (LEFT SIDE OF ENGINE COMPT) IGNITION COIL LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE NCA WIRE POWER STEERING PRESSURE SWITCH (RIGHT FRONT OF ENGINE COMPT) POWER TRANS- ISTOR POWERTRAIN CONTROL MODULE (BEHIND CENTER CONSOLE) RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE STARTING SYSTEM TO SPARK PLUGS WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/WHT WIRE

BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BRN/GRN WIRE CAPACITOR (LEFT SIDE OF ENGINE COMPT) CHECK ENGINE INDICATOR (MIL) COMBINATION METER CRANKSHAFT POSITION SENSOR (ON FRONT OF ENGINE) DEDICATED FUSE 2 DEDICATED FUSE 6 ENGINE COMPARTMENT RELAY BOX ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF ENGINE) GRN/BLU WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES INTAKE AIR TEMPERATURE SENSOR (ON INTAKE PLENUM, ON TOP OF ENGINE) J/C 3 (BEHIND LEFT SIDE OF DASH) J/C 5 (BEHIND RIGHT SIDE OF DASH) JUNCTION BLOCK JUNCTION BLOCK (ABOVE LEFT KICK PANEL) LT GRN/BLK WIRE MULTI- PURPOSE FUSE 4 NCA WIRE NOT USED RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE VEHICLE SPEED SENSOR (LEFT SIDE OF ENGINE COMPT) WHT/GRN WIRE YEL WIRE YEL/GRN WIRE YEL/WHT WIRE

AUTO-CRUISE CONTROL ECU (UNDER LEFT SIDE OF DASH) BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/RED WIRE BLU/YEL WIRE FUEL TANK DIFFERENTIAL PRESSURE SENSOR (ON TOP OF FUEL TANK) GRN/BLU WIRE GRN/WHT WIRE GRN/YEL WIRE J/C 3 (BEHIND LEFT SIDE OF DASH) J/C 5 (BEHIND RIGHT SIDE OF DASH) LT GRN WIRE MANIFOLD ABSOLUTE PRESSURE SENSOR (ON CENTER OF FIREWALL) NCA WIRE ORG/ WIRE RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE THROTTLE POSITION SENSOR (ON SIDE OF THROTTLE BODY ASSEMBLY) WHT WIRE WHT/GRN WIRE YEL WIRE YEL/RED WIRE YEL/WHT WIRE

1 (OR 3) A/C SYSTEM A/T CONTROL SOLENOID VALVE ASSEMBLY (ON TRANSAXLE) A/T FLUID TEMPERATURE SENSOR BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE COMBINATION METER DEDICATED FUSE 11 ENGINE COMPARTMENT RELAY BOX EXTERIOR LIGHTS SYSTEM (BACK-UP LAMPS CIRCUIT) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR START J/C 5 (BEHIND RIGHT SIDE OF DASH) JUNCTION BLOCK (ABOVE LEFT KICK PANEL) LOW, REVERSE LT GRN WIRE MULTI- PURPOSE FUSE 2 ORG/ WIRE OVER DRIVE PARK/NEUTRAL POSITION SWITCH (ON TRANSAXLE) POWERTRAIN CONTROL MODULE (BEHIND CENTER CONSOLE) RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE STOPLIGHT SWITCH UNDER- DRIVE SECOND TCC WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
