Mitsubishi Mirage V (1995-2003) off hi lo Wiring diagram
This page shows the only wiring diagram for the component.off hi lo, which is found in the car Mitsubishi Mirage V (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off hi lo (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CIRCUIT BREAKER
COLUMN SWITCH
HI OFF LO
HOT IN ACC OR ON
J/C 1 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (UNDER LEFT SIDE OF DASH, ABOVE KICK PANEL)
MULTI- PURPOSE FUSE 1
OFF HI LO
ON OFF
ORG/ WIRE
WINDSHIELD WASHER MOTOR (ON RIGHT SIDE OF ENGINE COMPARTMENT)
WINDSHIELD WASHER SWITCH
WINDSHIELD WIPER MOTOR (IN RIGHT REAR OF ENGINE COMPARTMENT)
WINDSHIELD WIPER SWITCH
Go to component -> 2-speed wiper/washer circuit -> OFF HI LO
