Mitsubishi Mirage V (1995-2003) left tail/ stop lights Wiring diagram
This page shows the only wiring diagram for the component.left tail/ stop lights, which is found in the car Mitsubishi Mirage V (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left tail/ stop lights (1 of 1)
2 3 ON
ABS SYSTEM
BLK WIRE
BLK/RED WIRE
BLU WIRE
COLUMN SWITCH
COMBINATION METER
COUPE
COUPE, SEDAN
CRUISE CONTROL SYSTEM TRANSMISSIONS SYSTEM
DEDICATED FUSE 10
DEDICATED FUSE 11
DEDICATED FUSE 7
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRN/ WHT WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD WARNING FLASHER UNIT
HAZARD WARNING LIGHT SWITCH
HEAD TAIL
HEAD- LIGHTS SYSTEM
HIGH MOUNTED STOP- LIGHT HIGH MOUNTED STOP- LIGHT
HOT AT ALL TIMES
HOT IN ON OR START
ILLUMINATION 4 5
INSTRUMENT CLUSTER SYSTEM
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 4 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (UNDER LEFT SIDE OF DASH, ABOVE KICK PANEL)
LEFT
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR COMBINATION LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT TAIL/ STOP LIGHTS
LEFT TURN LIGHT
LT GRN/BLK WIRE
MULTI- PURPOSE FUSE 9
NCA WIRE
NOT USED
OFF
OFF LIGHTING SWITCH
RED GRN/ WIRE
RED WIRE
RHEOSTAT
RIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT LICENSE PLATE LIGHT LEFT LICENSE PLATE LIGHT
RIGHT REAR COMBINATION LIGHT RIGHT TURN LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT TAIL/ STOP LIGHTS
RIGHT TURN IND LEFT TURN IND
SEDAN
SEDAN ONLY
SOLID STATE
STOP LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
TURN SIGNAL
TURN SIGNAL SWITCH
W/ CRUISE CONTROL
W/ REAR SPOILER
W/0 REAR SPOILER
W/O CRUISE CONTROL
WHT GRN/ WIRE
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> LEFT TAIL/ STOP LIGHTS
