Mitsubishi Mirage V (1995-2003) left front door switch right front door switch Wiring diagram
This page shows the only wiring diagram for the component.left front door switch right front door switch, which is found in the car Mitsubishi Mirage V (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door switch right front door switch (1 of 1)
BLK WIRE
BLU WIRE
COMBINATION METER
DEDICATED FUSE 2
DOME LIGHT
DOME LIGHT ROOM
DOOR
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT)
FOUR-DOOR
GRN WIRE
HOT AT ALL TIMES
JUNCTION BLOCK (UNDER LEFT SIDE OF DASH, ABOVE KICK PANEL)
LEFT FRONT DOOR SWITCH RIGHT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LUGGAGE COMPARTMENT LIGHT
MAP LIGHT
NCA WIRE
OFF ON OFF DOOR DOOR
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RIGHT REAR DOOR SWITCH
SPOT
TRUNK LID LATCH SWITCH
W/ SUNROOF
W/O SUNROOF
WHT WIRE
Go to component -> Courtesy lamps circuit -> LEFT FRONT DOOR SWITCH RIGHT FRONT DOOR SWITCH
