Mitsubishi Mirage V (1995-2003) hi lo lo off off int int int Wiring diagram
This page shows the only wiring diagram for the component.hi lo lo off off int int int, which is found in the car Mitsubishi Mirage V (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hi lo lo off off int int int (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CIRCUIT BREAKER
COLUMN SWITCH
HI LO LO OFF OFF INT INT INT
HOT IN ACC OR ON
INTERMITTENT WIPER RELAY
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 4 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (UNDER LEFT SIDE OF DASH, ABOVE KICK PANEL)
MULTI- PURPOSE FUSE 1
OFF
ORG/ WIRE
SOLID STATE
VARIABLE INTERMITTENT WIPER CONTROL SWITCH
WIND- SHIELD WASHER SWITCH
WINDSHIELD WASHER MOTOR (ON RIGHT SIDE OF ENGINE COMPARTMENT)
WINDSHIELD WIPER MOTOR (IN RIGHT REAR OF ENGINE COMPARTMENT)
WINDSHIELD WIPER SWITCH
