Mitsubishi Mirage V (1995-2003) abs ecu, powertrain control module, transaxle control relay wiring diagram

This page shows the only wiring diagram for the component.abs ecu, powertrain control module, transaxle control relay, which is found in the car Mitsubishi Mirage V (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

abs ecu, powertrain control module, transaxle control relay wiring diagram (1 of 1)

Login / Signup

List of components:

ABS ECU, POWERTRAIN CONTROL MODULE, TRANSAXLE CONTROL RELAY BATTERY BLK WIRE BLK/YEL WIRE HORN RELAY, RADIATOR FAN MOTOR LEFT REAR COMBINATION LIGHT, LEFT REAR SIDE MARKER LIGHT, HIGH MOUNTED STOPLIGHT LICENSE PLATE LIGHTS, RIGHT REAR COMBINATION LIGHT, RIGHT REAR SIDE MARKER LIGHT

---

Go to component -> Ground distribution circuit -> ABS ECU, POWERTRAIN CONTROL MODULE, TRANSAXLE CONTROL RELAY
