Mitsubishi Lancer X facelift (2011-2015) w/ audio amplifier pnk Wiring diagram
This page shows the only wiring diagram for the component.w/ audio amplifier pnk, which is found in the car Mitsubishi Lancer X facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ audio amplifier pnk (1 of 1)
10 D-30 10 D-26
26 36 28 38 C-104 26 36 28 38 C-107
34 D-29 3 34 D-25 3
6 C-24 6 C-21
7 17 1 10 12 3 2 C-106 7 17 1 10 12 3 2 C-109
BLK WIRE
BLU WIRE
C-130
C-133
C-311
C-317
ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH)
EVOLUTION
EVOLUTION EXCEPT EVOLUTION
EXCEPT EVOLUTION
FUSE 7
GRY WIRE
HANDS FREE MODULE (BEHIND RIGHT SIDE OF DASH)
HOT AT ALL TIMES
MICROPHONE UNIT
PNK PNK WIRE
PNK WIRE
RADIO, CD PLAYER
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
USB
USB ADAPTER
USB CABLE
VIO WIRE
W/ AUDIO AMPLIFIER PNK WIRE
W/O USB
WHT WIRE
WHT/GRN WIRE
YEL/GRN WIRE
Go to component -> Hands free module circuit, without multi-communication system -> W/ AUDIO AMPLIFIER PNK WIRE
