Mitsubishi Lancer X facelift (2011-2015) pnk 10 16 wiring diagram

11 C-115 11 C-126 13 C-22 24 C-115 24 C-126 6 C-36 ANTENNA AMPLIFIER AUDIO ADAPTER AUDIO SWITCH PANEL BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN WIRE C-128 C-204 C-205 C-311 C-313 C-317 C-39 CENTER PANEL UNIT CH UP VOL DN CH DN VOL UP CLOCK SPRING (IN STEERING COLUMN) COMBINATION METER COMPUTER DATA LINES SYSTEM D-01 D-20 ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH) FUSE 16 FUSE 7 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ ACC RELAY 2 ENERGIZED ILL ILL ILL INTERFACE CIRCUIT LCD PANEL (AUDIO, CLOCK) LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT TWEETER LT GRN WIRE MODE NAVIGATION SYSTEM NCA WIRE PICK HANG UP UP PNK 10 16 WIRE PNK WIRE RADIO, CD PLAYER RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT TWEETER ROOF ANTENNA SATELLITE RADIO TUNER (IF EQUIPPED) SPEECH STEERING WHEEL AUDIO REMOTE CONTROL SWITCH STEERING WHEEL VOICE CONTROL SWITCH TRANSCEIVER CIRCUIT VIO WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE
