Mitsubishi Lancer X facelift (2011-2015) passing switch auto switch (w/ automatic light) wiring diagram
This page shows the only wiring diagram for the component.passing switch auto switch (w/ automatic light), which is found in the car Mitsubishi Lancer X facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
passing switch auto switch (w/ automatic light) wiring diagram (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COLUMN ECU
COLUMN SWITCH-ECU (ON TOP OF STEERING COLUMN)
DIMMER SWITCH
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FOG LIGHTING SWITCH
FUSE 14 FUSE 15
FUSE 16 FUSE 17
FUSIBLE LINK 36
FUSIBLE LINK BOX (NEXT TO BATTERY)
GRN WIRE
HEAD LIGHTING SWITCH
HEADLIGHT CONTROL UNIT
HEADLIGHT RELAY (HIGH)
HEADLIGHT RELAY (LOW)
HI LO
HOT AT ALL TIMES
LEFT FOG LIGHT
LEFT HEADLIGHT ASSEMBLY
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OFF ON
ON OFF
PASS OFF OFF
PASSING SWITCH AUTO SWITCH (W/ AUTOMATIC LIGHT)
RIGHT FOG LIGHT
RIGHT HEADLIGHT ASSEMBLY
SOLENOID
TAIL LIGHTING SWITCH
VIO WIRE
WHT WIRE
Go to component -> Headlights circuit, with high intensity discharge (2 of 2) -> PASSING SWITCH AUTO SWITCH (W/ AUTOMATIC LIGHT)
