Mitsubishi Lancer X facelift (2011-2015) m/t cvt tc-sst Wiring diagram
This page shows the only wiring diagram for the component.m/t cvt tc-sst, which is found in the car Mitsubishi Lancer X facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram m/t cvt tc-sst (1 of 1)
7 C-49
A-10
A-60
B-108
B-109
B-13
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/RED WIRE
BRN WIRE
C-304
C-309
C-315
C-317
CLUTCH
COMPUTER DATA LINES SYSTEM
CVT
CVT TC- SST
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (LEFT REAR OF ENGINE COMPT)
ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH)
FUSE 14
FUSIBLE LINK 24
FUSIBLE LINK 34
FUSIBLE LINK 36
FUSIBLE LINK BOX (NEXT TO BATTERY)
GRN WIRE
GRN/RED WIRE
IGNITION SWITCH
INTERLOCK SWITCH (UNDER LEFT SIDE OF DASH)
LOCK
LT BLU WIRE
LT GRN WIRE
M/T
M/T CVT TC-SST
M/T, CVT TC-SST 6 3 A-10 A-60
NCA WIRE
PNK WIRE
RED/WHT WIRE
RUN WIRE
SHIFT LEVER (CENTER CONSOLE)
SHIFT LEVER POSITION SWITCH (N)
SHIFT LEVER POSITION SWITCH (P)
STARTER
STARTER RELAY (ON UNDERHOOD FUSE/RELAY BLOCK)
TC-SST
TRANSMISSION RANGE SWITCH (CVT) (TOP OF TRANSMISSION)
WHT WIRE
YEL WIRE
Go to component -> Starting circuit, except evolution -> M/T CVT TC-SST
