Mitsubishi Lancer X facelift (2011-2015) block, behind left end of dash) Wiring diagrams

This page contains all the electrical diagrams for the component. block, behind left end of dash), in which he is found in the car Mitsubishi Lancer X facelift (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram block, behind left end of dash) (1 of 3)

Wiring diagram block, behind left end of dash) for Mitsubishi Lancer X facelift (2011-2015) (1 of 3)

Get access

16 C-22 8 C-128 ABS IND BRAKE IND ASC IND ASC OFF IND (W/O COLOR LIQUID CRYSTAL DISPLAY) ASC OFF SWITCH BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLOCK, BEHIND LEFT END OF DASH) BLU/WHT WIRE BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID RESERVOIR) BRN WIRE C-301 C-304 C-311 C-312 C-313 C-315 C-317 C-35 C-51 CAN TRANSCEIVER CIRCUIT COMBINATION METER COMPUTER DATA LINES SYSTEM ETACS-ECU (ON REAR OF JUNCTION FUSE 12 FUSE 17 FUSE 2 FUSE 8 FUSE 9 GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES ILLUM INTERFACE CIRCUIT J/C 1 LCD (ASC OFF) (ASC OPERATION) (ASC WARNING) (BRAKE) (ABS) LED DRIVE CIRCUIT LT GRN WIRE NCA WIRE PARKING BRAKE SWITCH (UNDER CENTER CONSOLE) PNK WIRE RED/WHT WIRE RELAY ENERGIZED STEERING WHEEL SENSOR (IN STEERING WHEEL) STOPLIGHT SWITCH (UNDER LEFT SIDE OF DASH) WHT WIRE WHT/RED WIRE

Go to component -> 2.0l, anti-lock brakes circuit, with active skid control (2 of 2) -> BLOCK, BEHIND LEFT END OF DASH)

Wiring diagram block, behind left end of dash) (2 of 3)

Wiring diagram block, behind left end of dash) for Mitsubishi Lancer X facelift (2011-2015) (2 of 3)

Get access

2 15 16 D-11 5 C-35 6 C-35 ABS ABS IND. ASC IND ASC OFF SWITCH AWC SWITCH AWC-ECU (LEFT SIDE OF DASH) BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLOCK, BEHIND LEFT END OF DASH) BLU WIRE BLU/WHT WIRE BRAKE FLUID LEVEL SWITCH BRAKE IND BRAKE/ BRN WIRE BRN/WHT WIRE C-22 C-301 C-304 C-311 C-312 C-313 C-315 C-317 CIRCUIT COMBINATION METER COMPUTER DATA LINES SYSTEM D-11 ETACS-ECU (ON REAR OF JUNCTION FUSE 2 FUSE 8 FUSE 9 FUSE FUSE GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES ILLUM INTERFACE J/C 1 LCD LED DRIVE CIRCUIT LT BLU WIRE LT GRN WIRE NCA WIRE PARKING BRAKE SWITCH (UNDER CENTER CONSOLE) PNK WIRE PRESSURE SENSOR (UNDER RIGHT REAR OF LUGGAGE COMPT) PROPORTIONING VALVE (ACD CONTROL) (RIGHT REAR CORNER OF VEHICLE) RED/WHT WIRE RELAY ENERGIZED RHEOSTAT SNOW STEERING WHEEL SENSOR (IN STEERING WHEEL) STOPLIGHT SWITCH (UNDER LEFT SIDE OF DASH) TRANSCEIVER CAN VIO WIRE WHT/RED WIRE YEL/BLK WIRE

Go to component -> 2.0l turbo, anti-lock brakes circuit, except evolution with active skid control (2 of 2) -> BLOCK, BEHIND LEFT END OF DASH)
